EXO AX AX5400 Wi-Fi 6 Router
DIR-X5460

  • Wi-Fi 6 (802.11ax) technology provides faster speeds, greater capacity and less network congestion
  • Next-gen speeds up to AX5400 (4,800 Mbps on the 5 GHz band and 600 Mbps on the 2.4 GHz band)
  • Dual-band Wi-Fi with up to 6 simultaneous streams makes 4K streaming, VR gaming or video chatting a breeze
  • OFDMA and MU-MIMO technology communicate more data to more devices while simultaneously reducing lag
  • BSS coloring technology reduces interference in 'noisy' Wi-Fi environments, making more efficient use of available Wi-Fi spectrum
  • 4 Gigabit Ethernet LAN ports and 1 Gigabit Ethernet WAN port provide optional wired connectivity
  • Built in USB 2.0 and USB 3.0 ports to create shared storage
  • Intelligent Quality of Service (QoS) prioritizes network traffic to minimize the impact of busy bandwidth
  • Backwards compatibility ensures support for previous Wi-Fi standards and all Wi-Fi devices
  • Increased battery life of connected devices with Target Wake Time technology
  • Supports the latest Wi-Fi security with 128-bit encryption
  • Voice Control for an even easier home Wi-Fi networking experience
  • Works with the D-Link Wi-Fi App for easy setup and enhanced parental controls

  • Wi-Fi 6 (802.11ax) technology provides faster speeds, greater capacity and less network congestion
  • Next-gen speeds up to AX5400 (4,800 Mbps on the 5 GHz band and 600 Mbps on the 2.4 GHz band)
  • Dual-band Wi-Fi with up to 6 simultaneous streams makes 4K streaming, VR gaming or video chatting a breeze
  • OFDMA and MU-MIMO technology communicate more data to more devices while simultaneously reducing lag
  • BSS coloring technology reduces interference in 'noisy' Wi-Fi environments, making more efficient use of available Wi-Fi spectrum
  • 4 Gigabit Ethernet LAN ports and 1 Gigabit Ethernet WAN port provide optional wired connectivity
  • Built in USB 2.0 and USB 3.0 ports to create shared storage
  • Intelligent Quality of Service (QoS) prioritizes network traffic to minimize the impact of busy bandwidth
  • Backwards compatibility ensures support for previous Wi-Fi standards and all Wi-Fi devices
  • Increased battery life of connected devices with Target Wake Time technology
  • Supports the latest Wi-Fi security with 128-bit encryption
  • Voice Control for an even easier home Wi-Fi networking experience
  • Works with the D-Link Wi-Fi App for easy setup and enhanced parental controls

Specifications

Product Description AX5400 Wi-Fi 6 Router
Wireless Speed 600Mbps + 4800Mbps
SDRAM 512 MB
Flash 128 MB
Antenna Type 4 External Non-detachable; 2 External Detachable
Wi-Fi Mesh D-Link Wi-Fi Mesh
MU-MIMO Yes
D-Link Wi-Fi Yes
D-Fend N/A
D-Link SharePort Mobile N/A
mydlink SharePort N/A
D-Link QRS Mobile N/A
mydlink Lite (iOS/Android) N/A
McAfee Protection N/A
Voice Control Support (Amazon Alexa / Google Assistant) Yes
WAN 1
LAN 4
USB 2.0/3.0 1x USB 2.0 + 1x USB 3.0
Static IP Yes
Dynamic IP (DHCP) Yes
PPPoE Yes
L2TP Yes
PPTP Yes
Static IPv6 Yes
PPPoE (IPv6 over PPPoE) Yes
QuickVPN Yes
Wireless Security Latest Wi-Fi security with 128-bit encryption
WPS (Wi-Fi Protect Setup) Yes
Guest Zone Yes
USB Sharing (FTP) Yes
USB Sharing (SAMBA) Yes





The future is unstoppable, your Wi-Fi should be too.

Wi-Fi 6 brings next-generation Wi-Fi technology into your home, giving the quantum leap in capacity, speed and range you need to handle all your Wi-Fi demands. Perfect for high-performance, device-dense smart homes.

Learn More


Exceptional Capacity
Exceptional Capacity

Connect more devices at faster speeds


Made for Smart Home
Made for Smart Home

Better performance in device-dense environments


Next-Gen Speed and Range
Next-Gen Speed and Range

Combined speeds up to AX5400


Unprecedented Efficiency
Unprecedented Efficiency

Higher throughput, more efficient transmission

Why You Want It

Next-Generation Speed Next-Generation Speeds

The latest Wi-Fi 6 technology for blazing-fast Wi-Fi

Gigabit Ports OFDMA

Increased efficiency and lower latency for small data packets

Six Stream MU-MIMO MU-MIMO

Data to and from more devices at once

Extended Coverage Extended Coverage

Signals reach further throughout your home

Supports WPA3™ Encryption

The latest Wi-Fi security for more protection

BSS Coloring BSS Coloring

Color codes your data to minimize signal interference from your neighbors’ Wi-Fi

Test Internet Speed Test Internet Speed

Built-in internet test powered by Ookla® to check your connection uplink and downlink speeds

Voice Control Voice Control

Works with the Google Assistant and Alexa

Next-Generation Speeds

Experience up to AX5400 speeds while 1024-QAM boosts throughput to devices by up to 25% and 160 MHz contiguous channel width gives even more bandwidth. Up to 6 simultaneous streams let you enjoy faster, more enjoyable 4K streaming, online gaming and more, and should you require them - 4 Gigabit LAN ports and 1 Gigabit WAN port give you faster wired connectivity whenever you wish.

DIR-X1860 dimond
DIR-X1860 dimond
DIR-X1860 dimond

Connect More, Congest Less with OFDMA

The DIR-X5460 uses Wi-Fi 6’s cutting-edge Orthogonal Frequency Division Multiple Access (OFDMA) technology. Small data packets destined for multiple devices are transmitted together and never have to queue up again. Perfect for Smart Homes filled with bandwidth-hungry IoT devices battling for bandwidth.

Without OFDMA

OFDMA

MU-MIMO

MU-MIMO technology helps distribute the flow of data to multiple devices simultaneously. With Wi-Fi 6 technology the DIR-X5460 leverages OFDMA and MU-MIMO for better efficiency of upstream AND downstream transmissions, unlike previous Wi-Fi 5 technology where MU-MIMO could only operate in downstream transmissions. This combination greatly increases capacity, coverage and performance especially in ultra-high-density environments.

DIR-X1860

Extended Coverage, Reduced Interference

High-gain antennas, built-in power amplifiers and beamforming technology allow the DIR-X5460 to extend the reach of your Wi-Fi and focus a stronger signal in the direction of your devices to ensure a stronger, faster and more reliable Wi-Fi experience. Meanwhile a long OFDM symbol ensures even greater Wi-Fi range, especially outside the home.






The Future of Wireless Encryption

One of the biggest concerns with Wi-Fi networks and connected devices is privacy. The latest 128-bit encryption is the most advanced standard available and begins a new era of wireless encryption, ensuring greater privacy throughout users’ networks and devices.

The Future of Wireless Encryption

The Future of Wireless Encryption

Latest 128-bit encryption will replace previous industry-standard encryptions on Wi-Fi devices

Stronger Encryption Algorithm Stronger Encryption Algorithm

Creates stronger and more unique encryption keys for each device

Enhanced Protection from Brute Force Attacks Enhanced Protection from Brute Force Attacks

Stronger protection for users against password guessing attempts

Individualized Data Encryption Individualized Data Encryption

Creates stronger and more unique encryption keys for each device

Forward Secrecy Forward Secrecy

Cannot use a cracked password to decrypt previously-intercepted traffic

Futureproof and Compatible Futureproof and Compatible

D-Link routers will not be the ones holding your network back with previous encryption protocols

Conserve Energy, Save Battery Life

Target Wake Time (TWT) helps reduce battery consumption for connected devices by communicating with them and deciding when and how often the device requires data transfers. TWT increases the device’s sleep time, therefore cleverly extending the battery life of client devices and optimizing spectrum utilization.

DIR-X5460 Target Wake Time

Always Up-to-Date

Firmware upgrades can be a pain, but with the DIR-X5460, they are completely automated. Upgrades are so smooth, you won’t even notice them. On top of that, the DIR-X5460’s Dual Image functionality saves a recovery image as a backup before an upgrade. So, in the unlikely event an upgrade fails, the system has your pre-existing configuration to fall back on.

FOTA Server Router Firmware UpdateDownload Firmware UpdateRelease

BSS Coloring

Your neighbors’ Wi-Fi could be interfering with your wireless signals and slowing things down. Wi-Fi 6 puts an end to the Wi-Fi strife with BSS Coloring technology. It makes transmissions more unique by ‘coloring’ them with their own unique code.
The result? Devices can decide whether to transmit signals or ignore them, based on their “color”. Get less interference, less Wi-Fi slowdowns and more range.

BSS Coloring DIR-X5460
Internet Router Office

Virtual Private Networking Your Way

The DIR-X5460’s VPN Wizard lets you configure LAN-to-LAN and remote access VPN connections while its built-in passthrough feature also allows any devices connected to the router to establish outbound VPN connections.

True Internet Speeds Without the Guesswork

Tired of internet speeds that don’t live up to your ISP’s claims? The DIR-X5460’s integrated Internet Test lets you measure the true speed of your Router-to-ISP connection with the D-Link Wi-Fi app.

Speed test Powered

TRUE INTERNET SPEEDS
WITHOUT THE GUESSWORK TRUE INTERNET SPEEDS
WITHOUT THE GUESSWORK


Works with the Google Assistant and Alexa

Turn on/off your guest Wi-Fi, ask for your guest Wi-Fi credentials, reboot your router or update your firmware. Do it ALL hands-free using voice commands.

Just speak the words of command to your Google Assistant or Alexa, and the router bends your smart home Wi-Fi to your will (without you having to lift a finger).
Perfect for when you’ve got your hands full entertaining guests or just want to wow them with your smart Wi-Fi.

Works with the Google Assistant
Works with alexa

Supports the Google Assistant, Alexa, and IFTTT

Simple Setup and Management

Download the free D-Link Wi-Fi app for super simple setup and ongoing management. Set parental controls based on your family’s online needs, access your Wi-Fi settings and more, directly from your smartphone or tablet.

D-Link Wi-Fi
simple setup mydlink
