The 10G SFP+ modules enable versatile network configurations that can scale to support growing data traffic
Nuclias Network Controller enables centralized control for flexible and multiple device management
Effectively guards against power surges, minimizing downtime and costs, ideal for unstable regions
Provides versatile, advanced features to strengthen and safeguard network security for modern environments
ACLs protect the network by allowing trusted access and blocking unauthorized traffic effectively
Static routing handles inter-VLAN and inter-subnet traffic locally, enhancing overall network performance
The DGS-1250-28X switch delivers enhanced 6kV surge protection across all Gigabit Ethernet access ports, ensuring a resilient network and safeguarding connected devices from electrical surges and power spikes. This robust protection helps prevent hardware damage and maintains reliable operations even in regions with unstable power conditions.
The DGS-1250-28X switch offers a comprehensive set of Layer 2+ capabilities, including:
The DGS-1250-28X switch accelerates deployment with Auto Surveillance and Voice VLANs, utilizing QoS prioritization to ensure seamless, reliable VoIP and video traffic while automatically segmenting streams and maintaining optimal performance in high-traffic environments.
The DGS-1250-28X switch supports the Nuclias Network Controller for centralized management, simplifying device configuration and enhancing network efficiency. Features like device discovery, real-time monitoring, and updates ensure robust control and optimized operations.
User benefits :
Learn more :
Learn more :
Learn more :
|
Interfaces
|
24 x 1GE 4 x 10G SFP+ |
|---|---|
|
Switch Capacity
|
128 Gbps |
|
Max. Packet Forwarding Rate
|
95.24 Mpps |
|
Max Power Consumption
|
21.699 W/100 V 21.55 W/240 V |
|
Dimensions
|
440 x 140 x 44 mm (17.32 x 5.51 x 1.73 in) |
|
Weight
|
2.08 kg (4.58 lbs) |
|
Surge Protection
|
All Ethernet RJ-45 ports support IEC61000-4-5 6 kV surge protection |
|
FAN
|
1 Smart Fan |
|
Operating Temperature
|
-5°C to 50°C (23°F to 122°F) |
|
Storage Temperature
|
-20˚C to 70˚C (-4˚F to 158˚F) |
|
Operating Humidity
|
0% to 95% relative humidity |
|
Storage Humidity
|
0% to 95% relative humidity |
|
Console Port
|
RJ-45 console port |
|
Power Supply Type
|
Internal |
|
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice. |
|
