Vigilance 8 Megapixel H.265 Outdoor Dome Camera
DCS-4618EK

  • 1/2.5” 8-megapixel progressive CMOS sensor captures high-quality footage
  • Resolution of up to 3840 x 2160 at 20 fps
  • Motorized varifocal lens allows easy remote adjustment for the perfect field of view
  • Wide Dynamic Range (WDR) image enhancement improves footage quality in high contrast lighting conditions
  • H.265 compression strikes the perfect balance between high image quality and bandwidth efficiency
  • Motion Detection not only saves bandwidth, it also makes reviewing footage much less burdensome
  • Block out or mask sensitive areas with the Privacy Mask
  • Built-in IR LED illuminator with a 30m range for surveillance even in the dead of night
  • Vandal-resistant design with an IK10 rating and IP66 for environment protection
  • Fast Ethernet port with PoE facilitates easy integration to your network
  • All aspects of your camera are easily managed with the free D-ViewCam™ Video Management Software

  • 1/2.5” 8-megapixel progressive CMOS sensor captures high-quality footage
  • Resolution of up to 3840 x 2160 at 20 fps
  • Motorized varifocal lens allows easy remote adjustment for the perfect field of view
  • Wide Dynamic Range (WDR) image enhancement improves footage quality in high contrast lighting conditions
  • H.265 compression strikes the perfect balance between high image quality and bandwidth efficiency
  • Motion Detection not only saves bandwidth, it also makes reviewing footage much less burdensome
  • Block out or mask sensitive areas with the Privacy Mask
  • Built-in IR LED illuminator with a 30m range for surveillance even in the dead of night
  • Vandal-resistant design with an IK10 rating and IP66 for environment protection
  • Fast Ethernet port with PoE facilitates easy integration to your network
  • All aspects of your camera are easily managed with the free D-ViewCam™ Video Management Software

Specifications

Product Description Vigilance 8 Megapixel H.265 Outdoor Dome Camera
Video Compression h.265, H.264, MJPEG
Max. Resolution 8 Megapixel (Full HD)
Max. Frame 3840 x 2160
Image Sensor 1/2.5” Progressive Scan CMOS sensor
Day & Night- IR LED (Illumination Range) IR LED 30 Meters
Focal Length 3.3 mm - 12 mm
Aperture (F no. ) F1.4
Angle of View (Horizontal / Vertical) (H) 108.6° - 35° (V) 56° - 21° (D) 125° - 42°
Mechanical PTZ Pan & Tilt
Network Connectivity Wired
Storage Card Slot Yes
Power Input 100 to 240 V AC, 50/60 Hz
Power over Ethernet PoE Yes
Max. Power Consumption 8 W ± 5% (PoE)
Operating Temperature -30 to 50 °C
Dimension (W x D x H) 130 mm x 130 mm x 112 mm
Net Weight 750 g ± 5%
Indoor / Outdoor Outdoor
Digital PTZ (ePTZ) Yes
Digital Zoom Yes
Pan Range 355°
Tilt Range 10° - 90°
Vigilance Series

Surveillance Solutions That Bring Business Back Into Focus

With the Vigilance Series of cameras as the eyes of your IP surveillance network, footage that meets a higher standard is ensured. Top-quality lenses and state-of-the-art features that improve imaging are packed into a compact formfactor, rugged enough even for outdoor use.
