N300 Smart Router
R03

  • Wi-Fi 4 (802.11n) Technology with 300 Mbps speed
  • 1x 10/100 Fast Ethernet WAN Port
  • 4x 10/100 Fast Ethernet LAN Ports
  • Dipole antenna for data transmission and improves range and performance
  • Supports WPA,WPA2, and the latest WPA3 Wi-Fi Security
  • Essential firewall that equips with DMZ, SPI, anti-spoofing protection, and more
  • EAGLE PRO AI features including:
    • AI Wi-Fi Optimizer
    • AI Parental Controls
    • AI Assistant
    • Ookla Speed Test
    • QoS Technology

  • Wi-Fi 4 (802.11n) Technology with 300 Mbps speed
  • 1x 10/100 Fast Ethernet WAN Port
  • 4x 10/100 Fast Ethernet LAN Ports
  • Dipole antenna for data transmission and improves range and performance
  • Supports WPA,WPA2, and the latest WPA3 Wi-Fi Security
  • Essential firewall that equips with DMZ, SPI, anti-spoofing protection, and more
  • EAGLE PRO AI features including:
    • AI Wi-Fi Optimizer
    • AI Parental Controls
    • AI Assistant
    • Ookla Speed Test
    • QoS Technology

Specifications

Device Interfaces 4 x 10/100 Mbps LAN ports, 1 x 10/100 Mbps Ethernet WAN port, 1 x Reset/WPS button, 1 x power connector
Antenna Type 2 x external dipole antennas (5 dBi)
Wi-Fi Data Rate 2.4 GHz Up to 300 Mbps
Wireless IEEE Standard IEEE 802.11n/g/b, IEEE 802.3u/b, IEEE 802.11k/v
WAN Interface PPPoE, PPTP, L2TP, DS-Lite, Supports 802.1p & 802.1q; VLAN tagging and Priority bit, Concurrent session: 32,000
Security Protocol WPA/WPA2-Personal, WPA2-Personal only, WPA2/WPA3-Personal (WPS not supported), WPA3-Personal only (WPS Not supported)
Firewall DoS, Stateful Packet Inspection, Anti-spoofing Checking, IP/MAC Address Filtering, 1 x DMZ
QoS D-Link QoS Technology
SpeedTest Ookla SpeedTest
Device Management Eagle Pro AI app (iOS and Android), Web UI
Voice Assistant Amazon Alexa, the Google Assistant
Hardware version A1
Dimensions 158 x 131.35 x 35.75 mm (L*W*H)
Weight 150 g
Power Input 12V 1A
Maximum Operating Voltage 12V
Operating Temperature 0 to 40 °C (32 to 104 °F)
Storage Temperature -20 to 65 °C (-4 to 149 °F)
Operating Humidity 10% to 90% non-condensing
Storage Humidity 5% to 95% non-condensing
Certifications CE, FCC

R03 N300 Smart Router

Reliable and Affordable Wi-Fi

The R03 has the smarts to handle multiple wireless devices and enable smooth streaming and sharing across your entire home network. Proven cost-effective Wi-Fi 4 (802.11n) technology with 300 Mbps speed provides you the power you need for essential tasks on the internet — from 4K streaming to VoIP calls.

Supports WPA3 – The Latest Wi-Fi Security

The R03 supports the latest WPA3 Wi-Fi Security Protocol, which can help prevent brute-force password hacks, allows for more natural passwords, and secures past transmissions from being read, even if your password is exposed.

Supports WPA3 – The Latest Wi-Fi Security
AI Wi-Fi Optimizer

Always the Best Connection Possible

AI Wi-Fi Optimizer continuously scans the environment to keep you connected to the cleanest channel available.

QoS

Quality of Service

The Quality of Service (QoS) is evaluated data size and data size is used to filter the High and Lower priority data transmission. So, the users can set the manual priority  based on their essentials in EAGLE PRO AI App.

AI Parental Control

Keep Playtime Safe and Healthy

AI Parental Control lets you designate online hours for little ones and restrict website access to keep their learning experience a safe and healthy one.

Health Mode

Health Mode

  • Schedule Wi-Fi transmission hours to reduce possible effects of electromagnetic radiation
  • Schedule Wi-Fi access hours to maintain a balanced family lifestyle
  • Turn off Wi-Fi entirely to conserve energy


For Everything Wi-Fi,
there’s D-Link EAGLE PRO AI

The EAGLE PRO AI App managing your W-Fi has never been easier,
AI Assistant to continuously monitor data usage and provide actionable recommendations and weekly report.
Works with Google Assistant and Alexa

Works with Google
Assistant and Alexa

Easily integrates with Amazon Echo’s Alexa or the Google Assistant for convenient hands-free voice control.

*Please check availability in your region

Work with OK GoogleWorks With alexa
