Easy to use web interface to access management features.
Innovative D-Link Green power saving features
Supports DNA and D-View for remote setup and management
The DGS-1100 series’ web user interface gives administrators an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), and link aggregation (desktop models utilize Static Trunk). With powerful security features including IGMP snooping, Static MAC, and Storm Control, these smart managed switches are a versatile solution for deployments that require easy to configure functionality without added complexities.
The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily. Loopback Detection detects loops created by a specific port and automatically shuts down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. The desktop models in the series utilize a fanless design, for silent and energy-efficient operation. All models are also IEEE 802.3az-compliant and feature Link Status detection.
|
Interfaces
|
5 x GE |
|---|---|
|
Switching Capacity
|
10 Gbps |
|
Max. Packet Forwarding Rate
|
7.4 Mpps |
|
Max Power Consumption
|
3.42 W |
|
Dimensions
|
101 x 82 x 28 mm |
|
Weight
|
0.23 kg |
|
FAN
|
Fanless |
|
Operating Temperature
|
0°C - 40°C (32°F - 104°F) |
|
Storage Temperature
|
-40°C to 70°C ( -40°F to 158°F) |
|
Operating Humidity
|
0% to 90% RH, non-condensing |
|
Storage Humidity
|
0% to 95% RH, non-condensing |
|
Power Supply Type
|
External |
|
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice. |
|
