24-Port 10/100/1000 + 2 combo SFP Switch
DGS-1024T
- Product Status: End of Life
Description
With (24) 10/100/1000BASE-T ports, the DGS-1024T is designed to help provide a simple and economical migration path from 10BASE-T or 100BASE-TX to 1000BASE-T Gigabit.
The DGS-1024T blends plug & play simplicity with exceptional performance and reliability, to create cost effective solution for bandwidth-starved workgroups and departments. With (24) 10/100/1000BASE-T ports, the DGS-1024T is designed to help provide a simple and economical migration path from 10BASE-T or 100BASE-TX to 1000BASE-T Gigabit. Key features of DGS-1024T include:
High Performance Wire-Speed Architecture
The DGS-1024T delivers superior performance with exceptional value. With a forwarding capacity of up to 48Gbps with full duplex wire-speed forwarding, the DGS-1024T is an ideal solution for the most demanding bandwidth intensive applications.
Operational Simplicity
The DGS-1024T supports a wide array of plug & play features:
Investment Protection
The DGS-1024T helps to protect customers’ existing and future network infrastructure investments by:
The D-Link DGS-1024T is a flexible, high performance, value-oriented solution for a wide range of Gigabit applications.
With (24) 10/100/1000BASE-T ports, the DGS-1024T is designed to help provide a simple and economical migration path from 10BASE-T or 100BASE-TX to 1000BASE-T Gigabit.
The DGS-1024T blends plug & play simplicity with exceptional performance and reliability, to create cost effective solution for bandwidth-starved workgroups and departments. With (24) 10/100/1000BASE-T ports, the DGS-1024T is designed to help provide a simple and economical migration path from 10BASE-T or 100BASE-TX to 1000BASE-T Gigabit. Key features of DGS-1024T include:
- High Performance Wire-Speed Architecture
- Operational Simplicity
- Investment Protection
High Performance Wire-Speed Architecture
The DGS-1024T delivers superior performance with exceptional value. With a forwarding capacity of up to 48Gbps with full duplex wire-speed forwarding, the DGS-1024T is an ideal solution for the most demanding bandwidth intensive applications.
Operational Simplicity
The DGS-1024T supports a wide array of plug & play features:
- 10/100/1000BASE-T auto sensing
- Universal UTP cable recognition for straight-through or crossover cables
- Full/Half duplex support
- IEEE standards support
Investment Protection
The DGS-1024T helps to protect customers’ existing and future network infrastructure investments by:
- Providing a plug & play migration for existing 10/100BASE-TX devices to 1000BASE-T
- Standards based feature support to help insure multi-vendor compatibility
- Media flexibility through support of Mini-GBICs
The D-Link DGS-1024T is a flexible, high performance, value-oriented solution for a wide range of Gigabit applications.
Specification
Technical Specifications
Product/Performance Specifications
DGS-1024T
MAC Address Table Size
Switch Fabric
Transmission method
Diagnostic LEDs
Packet Buffer Memory
Interface Options
RJ-45
SFP/mini-GBIC Combo Expansion Slots
Network Protocol and Standards
IEEE
Electrical & Electrical Emissions Summary
Emissions
Power Supply
Safety Agency Certifications and Environmental
Safety
Temperature
Storage
Humidity
Physical Specifications
Dimensions (W x H x D)
Weight
Warranty and Support Information
Warranty
Support
Ordering Information
DGS-1024T
DGS-310GT
DGS-311GT
DGS-312GT2
Product/Performance Specifications
DGS-1024T
- (24) Ports 10/100/1000BASE-T with (2) Combo SFP/mini0GBICs Expansion Slots
MAC Address Table Size
- 32,000
Switch Fabric
- Up To 48Gbps Forwarding Capacity
Transmission method
- Store-and-forward
Diagnostic LEDs
- Per Unit: Power
- Per Port: Activity/Link & Speed
Packet Buffer Memory
- 8Mb Buffer Memory Per Device
Interface Options
RJ-45
- 10BASE-T, 100BASE-TX & 1000BASE-T
- Universal UTP Cable Recognition for Straight-Through or Crossover Cables (MDI/MDI-X)
SFP/mini-GBIC Combo Expansion Slots
- Media Support Is Dependent On Type Of SFP/mini-GBIC
Network Protocol and Standards
IEEE
- 802.3 Ethernet, 802.3u Fast Ethernet, 802.3x Flow Control & 802.3z Gigabit Ethernet & 802.3Z Gigabit Ethernet
Electrical & Electrical Emissions Summary
Emissions
- CE Mark, FCC Class A, BSMI, C-Tick
Power Supply
- 100-240VAC, 50/60 Hz Internal universal power
Safety Agency Certifications and Environmental
Safety
- CSA International
Temperature
- Operating: 0° - 40° C (32° - 104° F)
Storage
- -25° - 55° C (-13° - 131° F)
Humidity
- Operating: 5% to 95% RH, Non-Condensing
Physical Specifications
Dimensions (W x H x D)
- 441 x 388 x 66 mm (17.36 x 15.28 x 2.6 inches) 19-inch rack-mount width, 1.0U height
Weight
- 4.2 kg (9.26 lb.)
Warranty and Support Information
Warranty
- Limited 5 Year Warranty for as long as the original customer/end user owns the product, (excluding power supplies and fans) Power supplies and fans carry a limited 3 year warranty.
Support
- Free Technical Support
Ordering Information
DGS-1024T
- Unmanaged Layer 2 Switch with (24) 10/100/1000BASE-T Ports + (2) Combo** mini-GBIC Ports
DGS-310GT
- 1000BASE-LX SFP/mini-GBIC, Up to 5km (Singlemode) or Up to 550m (Multimode)
DGS-311GT
- 1000BASE-SX SFP/mini-GBIC, Up to 220m (Multimode)
DGS-312GT2
- 1000BASE-SX+ SFP/mini-GBIC, Up to 2km (Multimode) {Should Be Paired With: DEM-310GM2 or DEM-312GT2}
FAQ
- $name Read Answer
- $name Read Answer
- $name Read Answer
Support
This product was phased out on: 12/12/2004
This product's last date of support is on: 12/12/2006
