Dual WAN 4-Port Gigabit Wireless AC VPN Router
DSR-500AC
- Product Status: Live
The D-Link DSR Series Unified Services Routers provide secure, high-performance networking solutions to address the growing needs of small and medium businesses. With integrated high-speed wireless technology, the DSR series routers offer comparable performance to wired networks, but with fewer limitations.
Where to buyTake Data Rates to the Next Level
With integrated high-speed wireless technology, the DSR series routers offer comparable performance to wired networks, but with fewer limitations. Next generation wireless performance is available on the DSR-500AC, which introduces 802.11ac support to the family. Available on the 5 GHz band, the combination of wider Radio Frequency bandwidths take data rates available to clients supporting the wireless AC standard to the next level.
Flexible Deployment Options
With 3G mobile Internet connectivity support via an optional 3G USB dongle, the DSR Series offers the ability to stay connected when wired Internet is not available or as a backup if the wired Internet connection fails.
Security
This affordable, high-performance router also enables businesses to secure their network whether in the office, at home or out on the road. You and your colleagues can stay connected to the office anywhere, anytime. Complete VPN features, as well as IPSec Hub and Spoke technology, ensures secure communication between mobile employees and offices.
Web Content Filtering
The DSR series web content filtering feature to help administrators monitor, manage and control employees’ Internet usage. Static web content filtering helps to remove malicious objects such as Java applets, ActiveX, and cookies, or to block URLs by keyword. Dynamic web content filtering, which requires a license subscription, allows administrators to filter content from a list of categories. Multiple global index servers, with millions of URLs and real-time website data, enhance performance and maximize service availability.
Specification
| Product Range | Mid-range VPN Router |
|---|---|
| Ethernet Type | Gigabit Ethernet |
| Network Security | "IDP/DoS Protection Category-based Web Content Filtering Application Control/Management" |
| H/W Redundancy | N/A |
| WAN Load Balancing | Outbound Load Balancing |
| Wired/Wireless | 802.11AC |
| Port Configurable | 1 port configurable (WAN/DMZ) |
| WAN Redundency | Dual WAN Failover |
| Firewall Throughput | 950Mbps |
| VPN Throughput | 200Mbps |
| IPS Throughput | NA |
| AV Throughput | NA |
| New Sessions / Second | 500 |
| Firewall Policies | 600 |
| Concurrent Sessions | 50,000 |
| LAN Port | 4*GE |
| DMZ Port | Yes |
| WAN Port | 2*GE |
| Console Port | RJ-45 |
| USB Storage/Printer server | Yes |
| 3G Support | Yes |
| Transparent Mode | Yes |
| NAT, PAT | Yes |
| Dynamic Routing | OSPF/RIP v1,v2 |
| Static Route | Yes |
| Policy-based Routing | Yes |
| H.323 NAT Traversal | Yes |
| Application Layer Gateway (ALG) | Yes |
| Time-Scheduled Policies | Yes |
| DHCP Server/Client | Yes |
| DHCP Relay | Yes |
| IEEE 802.1q VLAN | Yes |
| IGMP | Yes |
| IPv6 | Yes |
| UPnP | Yes |
| One-to-One NAT | Yes |
| PPTP/ L2TP/ IPsec Pass Through | Yes |
| SSL VPN | Yes |
| VLAN (port-based) | Yes |
| SSID-to-VLAN Mapping | Yes |
| Wireless Isolation | Yes |
| WDS (Wireless Distribution System) | Yes |
| Multiple SSID | 4 |
| IPsec VPN Tunnel | 95 |
| X.509 v3 | Yes |
| XAUTH for IPSec Authentication | Yes |
| PPTP/L2TP Server | Yes |
| Hub and Spoke VPN | Yes |
| SSL VPN Tunnel | 10 |
| SSL Encryption Method | RC4-128 , RC4-56, 3DES |
| IPSec NAT Traversal | Yes |
| Encryption Method: (DES/3DES/AES/Twofish/Blowfish/CAST-128) | Yes |
| Built-in User Database | Yes |
| RADIUS Support | Yes |
| LDAP Support | Yes |
| Microsoft AD Support | Yes |
| Console Interface | RJ-45 |
| Web UI Interface | HTTP,HTTPS |
| Command Line/SSH | Yes |
| Upgrade and Config Backup/Restore | Yes |
| Trusted Host for Remote Management | Yes |
| Internal Log | Yes |
| External Log | Yes |
| Email Notification | Yes |
| Event log and alarm | Yes |
| SNMP | Yes |
| WAN Failover | Dual WAN+3G |
| Outbound Load Balancing | Round-robin Spill-over |
| Maximum Bandwidth | Yes |
| Guaranteed Bandwidth | Yes |
| Priority Bandwidth | Yes |
| Dynamic Web Content Filtering | Yes |
| DoS/DDoS Protection | Yes |
| Static URL Filter | Yes |
| WEP | Yes |
| WPA-PSK (Personal) | Yes |
| WPA-EAP (Enterprise) | Yes |
| WPA2-PSK (Personal) | Yes |
| WPA2-EAP (Enterprise) | Yes |
| VPNC AES | Yes |
| VPNC Basic | Yes |
| Operating Temperature | 0 to 40 °C |
| Storage Temperature | -20 to 70 °C |
| Operating humidity | 5% to 95% non-condensing |
| EMI | FCC Class B, CE Class B, C-Tick, IC |
| Safety | cUL, LVD (EN60950-1) |
| MTBF | 360,000 hours |
