Gigabit Passive PoE Injector

DPE-311GI

  • Product Status (Revision A): Live
  • Deliver up to 30 W PoE power
  • Gigabit connectivity, up to 100 metres2
  • Plug-and-play with no software required
  • Output: 0.54 A at 56 V
  • Lightweight and compact
  • Over-current, short circuit, over-voltage protection

Download the datasheet.

Where to buy

Extend Your Network

Power remote compatible D-Link PoE devices requiring a Gigabit connection in areas where power outlets are unavailable.

High Performance PoE

Offers a compact, powerful, and cost-effective for compatible D-Link PoE-enabled devices1, giving you maximum deployment flexibility.

Quick and Easy Installation

Installation is plug-and-play with no additional software requirements.

The Gigabit Passive PoE Injector combines a non-PoE Gigabit connection with Power over Ethernet (PoE) to provide data and power to a compatible D-Link PoE-enabled device1 over a single Ethernet cable. The Gigabit Passive PoE Injector is capable of supplying up to 30 W of PoE power, providing power to even the most power-hungry devices such as PTZ IP cameras or 802.11ac wireless access points. This allows you to mount compatible D-Link PoE-capable devices anywhere in a building, such as on ceilings or near entrances, by eliminating the need for a nearby power outlet.

Cost-Efficient Flexibility
Deploying the Gigabit Passive PoE Injector saves both installation costs and removes the need for dedicated PoE equipment, allowing a single Ethernet cable to carry both power and data to the connected device. This frees network devices from the restrictions of power availability. This reduces cable clutter, removes the need for dedicated electrical outlets in difficult-to-reach places, and cuts down deployment time.

Reliable Connectivity
The Gigabit Passive PoE Injector is equipped with several protection features to help keep connected devices safe from potential damage, including over-current protection, shortcircuiting protection, and over-voltage protection.


1 For a list of compatible products, please refer to datasheet below.
2 Maximum distance as per IEEE 802.3u specifications.

Support

Version Date Type File Size
Datasheet EN - PDF 0.25mb Download
