8-Port Fast Ethernet Switch
DES-1008E
- Product Status (Revision C1_v100): Live
- 8 high-speed Fast Ethernet ports
- Plug and play technology for simple setup
- IEEE 802.3x flow control, RoHs compliant to enhance network reliability
- Innovative D-Link Green energy saving features
- Compact design for convenient placement
- Fanless design for silent operation
Where to buy
Effortless High Speed Networking
The DES-1008E features easy access, auto sensing 10/100 Mbps Ethernet ports with an LED indicator for each port to quickly distinguish link status and activity. The DES-1008E switch also supports Auto MDI/MDIX Crossover allowing each port to be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables to get you the maximum speed possible for each device connected to your network.
Think Green
The DES-1008E 8-Port Fast Ethernet Switch is part of D-Link’s new series of home devices that make use of D-Link’s Green Technology, providing energy savings, reduced heat, and a longer product life without sacrificing performance or functionality. An energy-efficient power adapter (EnergyStar Level V qualified), minimized use of harmful substances (RoHS compliant), and recyclable packaging make this switch truly environmentally friendly.
Conserves Energy
The DES-1008E helps conserve energy automatically. The switch saves substantial amounts of power by cutting power usage for unused ports or ports connected to computers that have been shut down.
Environmentally Friendly
The DES-1008E is designed with the environment in mind, and is compliant with Energy Star Level V, as well as with the stringent CEC and MEPS regulations that require the use of energy efficient power adapters. It is also built to follow RoHS standards to minimize use of hazardous materials, and uses recyclable packaging that helps reduce waste, complying with the WEEE directive.
Specification
|
Interfaces
|
8 x 100Base-TX |
|---|---|
|
Auto MDI/MDIX
|
Yes |
|
Switching Capacity
|
1.6 Gbps |
|
Max. Packet Forwarding Rate
|
1.19 Mpps |
|
Store & Forwarding Forwading
|
Yes |
|
Dimensions
|
148.06 x 84.57 x 34.7 mm |
|
Weight
|
0.14 kg |
|
Operating Temperature
|
0 to 50 ˚C |
|
Storage Temperature
|
- 10 ~ 70 °C |
|
Storage Humidity
|
5% ~ 90% RH |
|
Operating Humidity
|
10% ~ 90% RH |
|
Maximum Power Consumption
|
2.19 W |
|
Maximum Heat Dissipation
|
7.47228 BTU/hr |
|
MTBF
|
2,137,319 hours |
|
Packet Buffer Size
|
96KBytes |
|
FAN
|
Fanless |
|
Power Saving By Cable Length
|
Yes |
|
Power Saving By Link Status
|
YES |
|
MAC Address Table Size
|
2,000 |
|
Control
|
802.3x Flow |
