5-Port Fast Ethernet Switch
DES-1005E
- Product Status (Revision C1_v100): Live
- 5 high-speed Fast Ethernet ports
- Plug and play technology for simple setup
- IEEE 802.3x flow control, RoHs compliant to enhance network reliability
- Innovative D-Link Green energy saving features
- Compact design for convenient placement
- Fanless design for silent operation
Where to buy
Effortless High Speed Networking
The DES-1005E features easy access, auto sensing 10/100 Mbps Ethernet ports with an LED indicator for each port to quickly distinguish link status and activity. The DES-1005E switch also supports Auto MDI/MDIX Crossover allowing each port to be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables to get you the maximum speed possible for each device connected to your network.
Environmentally Friendly
The DES-1005E is designed with the environment in mind. It's compliant with Energy Star Level V, as well as with the stringent CEC and MEPS regulations that require the use of energy efficient power adapters. The switch is also built to follow RoHS standards to minimize use of hazardous materials, and uses recyclable packaging that helps reduce waste, complying with the WEEE directive.
Think Green
The DES-1005E 5-Port Fast Ethernet Switch is part of D-Link’s series of home devices that make use of D-Link’s Green Technology, providing energy savings, reduced heat, and a longer product life without sacrificing performance or functionality. An energy-efficient power adapter (EnergyStar Level V qualified), minimized use of harmful substances (RoHS compliant), and recyclable packaging make this switch truly environmentally friendly.
Conserves Energy
The DES-1005E helps conserve energy automatically. The switches save substantial amounts of power by cutting power usage for unused ports or ports connected to computers that have been shut down.
Specification
|
Acoustic
|
0 dB |
|---|---|
|
Control
|
802.3x Flow |
|
FAN
|
Fanless |
|
MAC Address Table Size
|
2,000 |
|
Maximum Heat Dissipation
|
5.461 BTU/h |
|
Maximum Power Consumption
|
1.6 W |
|
MTBF
|
1,623,329 hours |
|
Power Input
|
AC:100 ~ 240 V |
|
Power Saving
|
By Cable Length By Link Status |
|
Auto MDI/MDIX
|
Yes |
|
Interfaces
|
5 x 1000Base-T |
|
Max. Packet Forwarding Rate
|
0.74 Mpps |
|
Operating Humidity
|
10% ~ 90% RH |
|
Operating Temperature
|
0 ~ 40 °C |
|
Storage Humidity
|
5% ~ 90% RH |
|
Storage Temperature
|
- 10 ~ 70 °C |
|
Store & Forwarding Forwading
|
Yes |
|
Switching Capacity
|
1 Gbps |
