mydlink Z-Wave Door/Window Sensor


  • Product Status (Revision A1_v100): Live

The DCH-Z112 mydlink™ Z-Wave Door/Window Sensor is a mydlink™ Connected Home Z-Wave contact sensor that detects when a door or window is opened or closed, providing you with a trigger for automating your home.

Download the datasheet.

Where to buy

Seamless Connected Home Integration

Integrating with D-Link’s own smart home ecosystem, the DCH-Z112 connects seamlessly with your D-Link Connected Home Z-Wave gateway, guaranteeing compatibility and getting your connected home network up and running right away.

Industry-Standard Encryption

The DCH-Z112 mydlink™ Z-Wave Door/Window Sensor features industry-standard 128-bit AES encryption for the connection between the sensor and your Z-Wave gateway.

Automate Your Home

Using the latest Z-Wave Plus technology, the mydlink™ Z-Wave Door/Window Sensor connects to your Z-Wave gateway, and acts as a trigger for your Connected Home network whenever someone opens or closes a door or window. Secure your home by automatically switching on mydlink-enabled cameras, receive instant notifications, or save power by automatically switching off the lights and other electronic devices when you go out.

Convenient & Intuitive Setup

The mydlink app for your smartphone or tablet allows you to get the DCH-Z112 up and running in minutes. Using D-Link’s mydlink smart home ecosystem, other D-Link products can be easily integrated with one another, ensuring maximum compatibility and greatly speeding up the connection process.

Product Description mydlink™ Z-Wave Door/Window Sensor
Device Interfaces Z-Wave v6.02 or above
Standard Z-Wave v6.02 or above
Wireless Frequency Range 868.40 MHz (Europe / China / Singapore / South Africa); 908.40 MHz (United States / Canada / Mexico / Chile)
Device Management mydlink™ app
Power Included 3 V battery (CR123A)
Dimensions 80 x 24 x 23 mm
Certifications FCC, CE, RCM, Z-Wave Plus
Antennas NA


Version Date Type File Size
Datasheet - PDF 0.23mb Download
