DGE-528T Copper Gigabit PCI Card for PC

DGE-528T

  • Product Status (Revision B): End of Life

The D-Link DGE-528T PCI Gigabit Ethernet Adapter is a high performance adapter that adds high-speed gigabit connectivity to any PC with an available PCI slot. It is specifically designed to allow throughput at rates up to 2 Gbps in an economical upgrade.

Advanced Features and Security

The DGE-528T features onboard screening of 802.1Q VLAN Tagged Ethernet frames, allowing you to assign multiple subnets to each server and isolate devices within each VLAN from the rest of the network for better traffic control and security. It also supports 802.1p Priority Tagging to allow you to prioritise traffic. Support for TCP, UDP, and IP checksum calculation as well as TCP Segmentation improves overall system performance by shifting CPU-intensive tasks away from the host CPU and onto the DGE-528T itself. Support for advanced features such as 802.3x flow control and Jumbo Frames for network management ensures interoperability with your current networking equipment.

Remote Management

The DGE-528T includes additional advanced features such as Advanced Power Management and Wake-on-LAN support. It also supports remote network boot using both PXE and RPL, allowing network administrators to boot the PC from anywhere on the network.

Versatility

The DGE-528T supports all major operating systems, guaranteeing compatibility with existing workstation and desktop environments. Its half-height form factor allows it to be used in low-profile cases for compact PCs. The card also has a diagnostic utility tool, simplifying
troubleshooting.

Type of ports
$name
Gigabit Ethernet
Type of device
$name
This product was phased out on: 17/09/2023
This product's last date of support is on: 04/06/2020

Downloads can vary across product revisions. Please select the correct hardware revision.
