Full HD Wireless Day Night Network Camera
DCS-2230L
- Product Status (Revision A): End of Life
Full HD Wireless Day/Night
Network Camera
The The D-Link DCS-2230L Full HD Wireless Day/Night Network Camera is a versatile camera perfect for monitoring low-light environments in your home or small office. It combines a high-resolution 2-megapixel sensor with a built-in IR LED to help you keep watch over areas in complete darkness.
Monitoring Your Home Has Never Been Easier!
HD 1080p High Quality Video
Push Alert Notifications
Two-Way Audio
Snapshots
Motion detection
microSD/SDHC Card Slot1 - Record snapshots and videos triggered by motion or sound
Easy Do-it-Yourself Setup
-
Step1: Install
-
Step 2: Place
-
Step 3: Monitor
Download the free mydlink® app for your iPhone, iPad or Android device and follow the simple
steps to set up your camera.
mydlink® App
Whether you're at home or on-the-go, the mydlink® app keeps you connected and allows you to manage all of your camera's features directly from your mobile device.
Full HD 1080p High
Quality Video
Never miss a detail with the sharp clarity of 1080p Full HD picture for the best monitoring experience.
Survey a large area easily
Get a closer look with ePTZ, which lets you zoom in, zoom out,
and pan across your camera’s video so you can survey a large area easily.
PIR Motion
Detection
Receive alert notifications when movement is detected.
Photo Snapshots
Save your photos directly to your mobile device's photo folder for easy sharing.
10x Digital Zoom
View more details of your baby with a few simple gestures.
D-ViewCam2
If you want to expand your surveillance options, D-ViewCam™ management software is also included, giving you the ability to manage up to 32 cameras with a robust set of features, including multi-camera views and automated e-mail alerts to keep you informed of suspicious or unusual activities.
1 MicroSD card not included
2 D-ViewCam software included is not Mac-compatible.
2 D-ViewCam software included is not Mac-compatible.
Specs
|
Indoor/outdoor
|
Indoor |
|---|---|
|
Connectivity
|
Wired Wireless |
|
Resolution
|
Full HD 2 megapixel |
|
Image sensor
|
1/2.7" 2 megapixel progressive scan CMOS |
|
Maximum Video Resolution
|
1440 x 1080 (other) 1920 x 1080 (16:9) |
|
Lens
|
2.8 mm F1.8 Fixed |
|
Infrared-Cut Removable Filter
|
Supported
|
|
Night vision
|
Supported
|
|
Night vision range
|
5 m |
|
PIR(Passive Infrared)sensor
|
Supported
|
|
Privacy Masks
|
3 zones |
|
2-way audio
|
Supported
|
|
Built-in Microphone
|
Supported
|
|
Built-in Speaker
|
Supported
|
|
Digital Input/Output(DI/DO)
|
1/1 |
|
External Card Slot
|
MicroSD SDHC (max 32 GB) |
|
App Support
|
mydlink |
|
Features
|
ONVIF |
|
Video Format
|
H.264 MJPEG MPEG-4 |
|
Multi-Stream
|
Supported
|
|
Mobile Stream
|
Supported
|
|
Digital Zoom
|
10x |
|
Motion Detection
|
Supported
|
|
Event Recording
|
Supported
|
|
E-mail Notification
|
Supported
|
|
Recording to NAS
|
Supported
|
This product was phased out on: 25/07/2018
This product's last date of support is on: 24/07/2020
