10-Port 10/100 Long Range PoE+ Surveillance Switch

DES-F1010P-E

  • Statut produit (Revision Datasheet_ME): Live

Superior connectivity

  • 8 10/1 0OMbps Fast Ethernet ports
  • 2 10/1 0OMbps uplink port
  • 96 watts available for PoE
  • Flow control for protection against data loss
  • Maximum distance of 250m

Standards

  • IEEE 802.3 1 0BASE-T Ethernet (twist-pair copper)
  • IEEE 802.3u 1 00BASE-TX Fast Ethernet (twisted pair copper)
  • IEEE 802.3af Power over Ethernet
  • IEEE 802.3at Power over Ethernet

Easy to Use

  • Plug-and-play installation
  • IEEE 802.3x Flow Control
  • Auto MDI I MDIX crossover for all ports
  • Fanless device

Télécharger Fiche technique

Voir la liste de nos partenaires

High transmission distance

With high distance connectivity, ideal for surveillance solution. Can be used with cat5e or cat6 cable.

IEEE 802.3af /at Power over Ethernet (PoE)

The DES-F1010P-E features eight 10/100BASE-TX ports that support the IEEE 802.3af/at PoE protocol. With total power budget of 120W, each of the these PoE ports can supply up to 15W.

Plug & Play Installation

The DES-F1010P-E is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. 802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.

100Base-TX Interface Ethernet RJ-45 port
Auto MDI/MDIX Yes
Switching Capacity 2 Gbps
Max. Packet Forwarding Rate • 1 OM: 14,800pps• 1 QOM: 148,800pps
Dimension (LxWxH): 184 x 94 x 27mm
Weight 0.95kg
Operation Temperature Oto 40 °C (32 to 104 °F)
Operation Humidity 10% to 90% non-condensing
Maximum Power Consumption External Power adapter: 100-240 ~ 50/60Hz, 52V/1.85A
FAN Fanless
802.3x Flow Control Yes
