1000BaseT to 1000BaseSX (SC) Multimode Media Converter

DMC-700SC

  • Product Status: End of Life
Description

The DMC-700SC by D-Link® is a media converter designed to connect 1000BASE-SX fiber to 1000Base-T copper media or vice versa. Based on the IEEE 802.3ab and 802.3z standards, the DMC-700SC is designed for use with multi-mode fiber cable utilising the SC-Type connector. The DMC-700SC supports shortwave (SX) laser specifications at a full wire-speed forwarding rate. Other features of this module include the ability to be used as a standalone device (no chassis required), Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The DMC-700SC will transmit at extended fiber optic distances utilising multimode fiber up to 550 meters.
LED Indicators
  • Power (PWR)
  • LINK/ACT

Dimensions
  • 120 x 88 x 25 mm

Power Input
  • 7.5V 1.5A
  • Through external AC power adapter

Operating Temperature
  • 0° -  40° C

Storage Temperature
  • -25° -  70° C

Humidity
  • 10  ~  90% non-condensing

Emission (EMI)
  • FCC Class B
  • VCCI Class B
  • CE Class B
  • C-Tick
This product was phased out on: 28/09/2023
This product's last date of support is on: 13/05/2024

Downloads can vary across product revisions. Please select the correct hardware revision.
