10-Port Multi-Gigabit PoE Smart Managed Switch
DMS-1100-10TP
- Status produktu (Revision A1): W sprzedaży
- x8 2.5 Gigabit PoE/PoE+ ports
- x2 10 Gigabit SFP+ uplink ports
- Layer 2 management and security
- PoE options up to 240W power budget
- Designed for Wi-Fi 6 access points
- Limited Life Warranty after registration
Lista sklepów
![](/pl/pl/-/media/product-pages/dxs/1210/assets/dxs1210_icon_10g.png)
Porty 10G Multi-Gigabit
Połączenia 10G Multi-Gigabit to gwarancja elastyczności i wysokiej przepustowości.
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms-1100-10tp-1-port.png)
2.5 Gigabit PoE ports
8 x 100/1000/2.5GBASE-T PoE/PoE+ ports for rapid and reliable Ethernet connections and power to devices via a single cable.
![](/pl/pl/-/media/product-pages/dxs/1210/assets/dxs1210_icon_management.png)
Interfejs GUI
Intuicyjny interfejs zdalnego zarządzania ułatwia konfigurację oraz skraca czas wdrożenia przełączników.
![](/pl/pl/-/media/product-pages/dxs/1210/assets/dxs1210_icon_l2.png)
Funkcje L2
Obejmują port mirroring, Spanning Tree Protocol (STP) oraz Link Aggregation Control Protocol (LACP).
![](/pl/pl/-/media/product-pages/dxs/1210/assets/dxs1210_icon_qos.png)
Quality of Service (QoS)
Rich QoS controls, including bandwidth control, and Auto Surveillance VLAN.
![](/pl/pl/-/media/product-pages/dxs/1210/assets/dxs1210_icon_security.png)
Network Security
D-Link’s Safeguard Engine™ helps protect against traffic flooding from malicious attacks.
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms-1100-10tp-9-2-energy.png)
Energy Saving Technology
Supports LED shutoff, and complies with IEEE 802.3az Energy Efficient Ethernet (EEE).
Futureproof your network. Ready for Wi-Fi 6.
Ideal for businesses looking to upgrade to Wi-Fi 6, the DMS-1100-10TP has 2.5 Gigabit PoE ports and 10 Gigabit SFP+ uplink ports, providing the multi-gigabit connectivity needed to maximise throughput between access points and the network infrastructure.
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms-1100-10tp-9-overview.png?h=550&w=2000&la=pl-PL&hash=14C0290680B9ECC3D9984F71475B8501)
Affordable 10G capabilities, for a reliable high-speed network.
Add 10-Gigabit Ethernet connectivity to your network with this cost-effective switch. Integrate it into existing Gigabit Ethernet network infrastructures while simultaneously futureproofing the network.
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms-1100-10tp-10-speed.png?h=752&w=1180&la=pl-PL&hash=D8C8D7EC0C565F9A2E3645EFE41E7BB8)
Ready for Wi-Fi 6.
You can add a Wi-Fi 6 Access Point to your network to any of the 2.5 Gbps ports to maximise throughput and speed. Multi-Gigabit Ethernet eliminates potential bottlenecks with Wi-Fi 6 Access Points, allowing your network to take full advantage of the efficiency and speeds provided by Wi-Fi 6.
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms110010tp-26-multigigabitports-wifi6.jpg?h=544&w=746&la=pl-PL&hash=7A7590155C4624DF5A795333F0F54117)
Extensive Layer 2 features.
Utilise a full line up of Layer 2 features such as: port mirroring, Spanning Tree Protocol (STP/MSTP/RSTP),Link Aggregation Control Protocol (LACP), IGMP and MLD Snooping, auto voice and surveillance VLAN 2.0, and LLDP and LLDP-MED.
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms-1100-10tp-20-features.png?h=560&w=560&la=pl-PL&hash=C964E823B3887983C229B1C52CE2C111)
PoE and PoE+, with budgets up to 270W
PoE and PoE+, with budgets up to 270W
Includes a high-power budget for businesses looking to power larger deployments of VoIP phones, wireless access points or network cameras.
Security with every port.
The innovative D-Link Safeguard Engine protects the switches against traffic flooding caused by malicious attacks and increases overall network reliability.
This switch also features support for traffic segmentation, Broadcast/Multicast/Unknown Unicast Storm Control, and DoS attack prevention.
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms-1100-10tp-22-security.png?h=630&w=560&la=pl-PL&hash=51B719AF8778996B80706631E58E0E67)
Versatile network management options.
The DMS-1100-10TP can be configured quickly and easily through the web-based management interface. Built-in smart wizard and dual configuration give network administrators more options and flexibility.
Also supports D-View Network Management Software that allows central management of critical network characteristics such as availability, reliability, resilience, and security.
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms-1100-10tp-23-management.png?h=267&w=2000&la=pl-PL&hash=B0B583855B00E4B2615269A6E2D315EC)
![](/pl/pl/-/media/product-pages/dms/1100-10t/assets/dms-1100-10tp-24-das.png?h=310&w=2000&la=pl-PL&hash=2242BA48087D1573807C760D5B791B9E)
Bezpłatna usługa Next-Business-Day (NBDS)
Skorzystaj z naszej bezpłatnej usługi Next Business Day dedykowanej rozwiązaniom biznesowym, aby szybko wymienić uszkodzony sprzęt.
![](/pl/pl/-/media/product-pages/dwl/6620aps/assets/dwl6620aps_14_assistlogo.png?h=92&w=224&la=pl-PL&hash=7C0EABD04E94FCB2B99911FE83B266DF)
![](/pl/pl/-/media/product-pages/common/callouts/icon_35years.png?h=113&w=142&la=pl-PL&hash=1877CE4C0A168636AD03ED090E62CD8B)
Ponad 35 lat doświadczenia
Innowacyjne, kompleksowe rozwiązania dla małych i średnich przedsiębiorstw jak również użytkowników domowych.
![](/pl/pl/-/media/product-pages/common/callouts/icon_support.png?h=113&w=86&la=pl-PL&hash=CA780C9DDD16938617D7383D42C6AB2C)
Porozmawiajmy
Wykwalifikowane wsparcie lokalne w 16 krajach. Nasze zespoły wsparcia są gotowe, aby Ci pomóc.
![](/pl/pl/-/media/product-pages/common/callouts/icon_limitedlifetime_warranty.png?h=113&w=108&la=pl-PL&hash=ABB44A784F4C42FEFB4BD2321792FE14)
Dożywotnia gwarancja Lifetime-Limited
Zapewniamy dożywotnią gwarancję Lifetime-Limited dla urządzeń D-Link. Wymagana jest rejestracja produktu.
Sugerowane urządzenia
![](/pl/pl/-/media/product-pages/dms/107/dms_107_a1_front.png?h=100&w=257&la=pl-PL&hash=84824DB04A75F3AEEBA51346FF048300)
![](/pl/pl/-/media/product-pages/dms/106xt/dms_106xt_a1_front_colour_rd.png?h=100&w=140&la=pl-PL&hash=B82377976626CD6DF089545BE7941431)
![](/pl/pl/-/media/product-pages/dgs/1520/dgs_1520_28_28mp_52_52mp_a1_front.png?h=100&w=191&la=pl-PL&hash=D421263CF5A1DC2C6EDA3AABBAE154CC)
![](/pl/pl/-/media/product-pages/dxs/1210/b1/dxs121010ts12tc12sc16tcb1image-lfront.png?h=100&w=191&la=pl-PL&hash=2BAD1E85B28DF859DE7F4400739958F9)
Dane techniczne
Rodzaj przełącznika
|
Zarządzalny Smart |
---|---|
Liczba portów
|
5 - 10 portów |
Warstwa
|
Layer 2 |
Rodzaj portów
|
2.5GBASE-T Ethernet |
Rodzaj portów uplink
|
10GbE SFP+ |
Standard PoE
|
802.3af 802.3at |
Liczba portów PoE
|
8 |
Budżet PoE
|
201 do 400W |
802.3az Energy-Efficient Ethernet support
|
Supported
|
Montaż
|
Szafa Rack |
Obudowa
|
Metal |
Ramki Jumbo
|
Supported
|
Diagnostyka kabla
|
Supported
|
MAC address
|
16K |
Spanning Tree Protocol
|
802.1D STP 802.1s MSTP 802.1w RSTP |
Ethernet ring protection switching (ERPS)
|
Supported
|
Agregacja linków
|
802.3ad |
VLAN group (max static)
|
4K |
Typ VLAN
|
w oparciu o adresację MAC w oparciu o port |
Advanced VLAN
|
Asymmetric VLAN Auto Surveillance VLAN Voice VLAN |
Liczba kolejek QoS na port
|
8 |
Kontrola przepustowości
|
1 Kbps minimum granularity |
SNMP (v1/v2c/v3)
|
Supported
|
LLDP
|
Supported
|
LLDP-MED
|
Supported
|
