Vigilance 3-Megapixel Vandal Proof Outdoor Dome Camera

DCS-4633EV

  • Product Status (Revision A): End of Sale

High-resolution vandal-proof surveillance

The D-Link DCS-4633EV Vigilance 3-Megapixel Vandal-Proof Outdoor Dome Camera is a professional security camera crafted for the growing demands of modern surveillance, delivering truly superior quality video in all conditions.

3 Megapixel resolution with x10 digital zoom

A high-resolution sensor provides 2048x1536 resolution while Wide Dynamic Range (WDR) technology ensures improved quality image in any light

Vandal & Weatherproof

The IP66 and IK10 ratings make it ideal for even the most demanding of surveillance locations

Day & Night Monitoring

Keep watch 24 hours a day. See up to 20 meters in complete darkness

Tampering & Motion Detection

Know exactly what’s happening with instant event notifications for tampering and motion detection

Free Surveillance Management Software

Includes D-ViewCam - view, manage, and record with up to 32 cameras

Easy installation with PoE

Power Over Ethernet (PoE) support allows easy installation in a variety of locations without the need for additional power cabling or sockets

High-Quality Streaming & Recording

The DCS-4633EV uses a powerful 3-megapixel CMOS sensor providing clear 2048 x 1536 resolution footage. It provides up to 3 simultaneous streams for monitoring and recording, incorporating H.265 compression and noise reduction to maximise bandwidth efficiency and image quality.

The microSD card slot gives you the ability to store and record up to 256GB of footage locally for extra backup protection.

Uninterrupted surveillance in any situation

Wide Dynamic Range (WDR) image enhancements deliver improved quality in conditions with uneven or difficult lighting. Built-in IR LED illuminators with a 20-metre range, allow the DCS-4633EV to keep watch even in complete darkness.

The IP66 certification ensures the camera is completely protected from dust and water in any environment, and its IK10 certified vandal-proof housing along with tamper detection ensures uninterrupted surveillance even if intruders attempt to sabotage the camera.

Flexible Connectivity

Built-in PoE simplifies installation by providing power and networking connectivity with a single cable, and can significantly reduce deployment time and costs.

Complete Management Software

D-ViewCam, a free and complete surveillance software package, is included with the camera and enables you to view, manage, and record from up to 32 cameras in a central location. Recordings and e-mail alerts can be triggered by motion detection or by external digital input devices, keeping a record of any unusual activity.

Download D-ViewCam

Save bandwidth

H.265 High-Efficiency Video Encoding can significantly reduce required network bandwidth. The DCS-4633EV also supports H.264, and MJPEG codecs for streaming and recording.

Related Products

Smart+ Managed Gigabit Switches
DGS-1210-10, DGS-1210-10P, DGS-1210-10MP, DGS-1210-20, DGS-1210-26, DGS-1210-28, DGS-1210-28P, DGS-1210-28MP (Max PoE), DGS-1210-52, DGS-1210-52MP (Max PoE)
Find out more
Indoor/outdoor
Indoor
Outdoor
Type
Dome
Connectivity
Wired PoE
Resolution
3 megapixel
Image sensor
1/3" 3 megapixel progressive scan CMOS
Maximum Video Resolution
1920 x 1080 (16:9)
2048 x 1536 (other)
Advanced Light features
Wide Dynamic Range
Lens
2.8 mm
F1.85
Fixed
Angle of View (H/V/D)
105° / 80° / 137°
Infrared-Cut Removable Filter
Supported
Night vision
Supported
Night vision range
20 m
Wide Dynamic Range(WDR)
Supported
Privacy Masks
3 zones
Vandal Proof
Supported
External Card Slot
MicroSD SDHC SDXC (max 256 GB)
Power Consumption
6 W
App Support
JustConnect+
Features
D-ViewCam D-Link NVR compatible
MicroSD Card slot
ONVIF
Video Format
H.264
H.265
MJPEG
Multi-Stream
Supported
Mobile Stream
Supported
Digital Zoom
10x
Motion Detection
Supported
Tamper Detection
Supported
Event Recording
Supported
E-mail Notification
Supported
Recording to NAS
Supported

1 Frame rates when streaming video may vary depending on network conditions and method used.
2microSD card not included. microSD/SDHC/SDXC v3.1 compatible.

This product was phased out on: 05/05/2021
