| CCTV Cable | 100VAC~240VAC |
| Frequency | 50Hz - 60Hz |
|---|---|
| Output Voltage | 12V±5% |
| Line Regulation | ?5% |
| Setup Rise time | ?5S |
| Hold up time |
10ms |
| Inrush current | < 50A |
| Leakage Current | <0.25mA |
| Auto Reset | Yes |
| Input Overvoltage Protection | The power supply is withstanding upto 240VAC, without Interrupting |
| Over Load Protection | Auto restart |
| Ripple | ?80mV |
| Surge protection | 3.5 KV |
| Efficiency | ?80% |
| Housing | ABS white Plastic |
| Store Temperature | -20?~ +80? |
| Working Humidity | 10 ~ 90% |
| Working Temperature | 0?~ +50 |
| Dimension | L: 153.6mm, W: 98mm, H: 33.83mm |
| Version | Date | Type | File Size | |
|---|---|---|---|---|
| Datasheet | - | - | - | Download |
