65W Adapter with Triple port output. (Type C1 +Type C2+ Type A)

DPA-F6521

  • Product Status (Revision IN): End of Sale

Performance & Fast charging

DPA-F6521 is a Power Delivery and Quick Charge Fast charging adapter. This device has two USB C ports and one USB-A port for charging. It can provide up to 65W output for charging Laptop and mobile devices. Fast charging is compatible with PD and QC compatible devices.

Specification

Download the datasheet.

Model No DPA-F6521
Connector Type Type C1 + Type C2 + Type A
Input Voltage 100-240V (AC) 50-60Hz
Type C1 Output DC 5V/3A, 9V/3A,12V/3A, 15V/3A, 20V/3.25A
Type C2 Output DC 5V/3A, 9V/3A,12V/3A, 15V/3A, 20V/3.25A
USB A Output DC 5V/3A, 9V/3A,12V/2.5A, 20V/1.5A
Ambient Condition 80%
Supported Charging Protocols USB-C Port Apple2.4A, Samsung-5V-2A QC3.0-3.6V-15.6V DCP-1.5A QC2.0-9V-12V-20V Samsung-AFC-9V-12V Huawei-FCP-9V-12V-24.0W Huawei-SCP-3.4~5.5V-25.0W PD3.0 PPS 65W MTK-PE+2.0; USB-A Port Apple2.4A, Samsung-5V-2A QC3.0-3.6V-15.8V DCP-1.5A QC2.0-9V-12V-20V Samsung-AFC-9V-12V Huawei-FCP-9V-12V-24.0W Huawei-SCP-3.4~5.5V-25.0W MTK-PE+2.0
Max. Wattage 65Watts (Max)
Operating Temperature 0 to 40°C
Dimension 70 X 60 X 30 mm
Weight 131 grams
Compliance of Standards BIS

Support

This product was phased out on: 28/02/2026
Version Date Type File Size
Datasheet - PDF 0.32mb Download
