| Video & Audio Input | |
| IP Video Input | 16ch |
|---|---|
| Audio Input | N/A |
| Video & Audio Output | |
| HDMI | 1 CH HDMI output (3840×2160@ 30Hz, 1920×1080@60Hz, 1280×1024 ,1440X900,1280X720,1024X768 @60Hz) |
| VGA | 1 CH VGA output (1920×1080@60Hz 1280×1024@60Hz) |
| Audio Output | N/A |
| Recording | |
| Compression | H.265 /H.264 |
| Resolution | 4K/5MP/3MP/1080P/720P/D1/VGA/CIF/QCIF |
| Playback & Backup | |
| Playback Mode | Smart/ Normal/ Time Division/ Label/ Event/ Picture/ Log Playback |
| Decoding Capability | 4×4K/25fps (Mainstream), 4*D1/25fps (Sub Stream) |
| Backup Mode | USB Device/Network |
| Advance Features | |
| Smart Detection | Line crossing, Area Intrusion, Fast moving, Unattached Object, Object Missing |
| Smart Playback | Line Crossing/Area Intrusion /Motion Detection |
| Cloud Storage | Support |
| Cloud Upgrade | Support |
| Network | |
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 80 Mbps |
| Ethernet | 1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface |
| Network Compatibility | HTTP, HTTPS, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, IP Filter, DDNS, FTP, P2P, ONVIF 2.6 |
| Smart Phone | IOS (iPhone, iPad), Android (Phone, Pad) |
| Hard Disk | |
| SATA | 1 SATA interface |
| Capacity | Up to 10TB capacity for each HDD |
| Ethernet Interface | |
| USB Interface | Rear panel: 2 × USB 2.0 |
| General | |
| Working Environment | -10°C~+60°C / 10%~90%RH |
| Power Supply | DC 12V 2Amp |
| Dimension (W×D×H) | 192mmx192mmx42mm |
| Power Consumption | <10W (without HDD) |
| Weight | 340 g |
