DIS-F200-10PS

8 Port PoE + Gigabit Rugged Switch

DIS-F200-10PS

Product Status (Revision IN): Live

Full wire speed layer 2+ switching with 20 Gbps switching capacity
IPv4 & IPv6 Static Routing
Built-in 8 Gigabit PoE+ ports compliant with IEEE 802.3af/at standards
Up to 30W output per PoE+ port
PoE diagnostic for PD analysis
2 1000Base SFP or 1000 Base-T Combo ports
Operates with 240 watts full PoE+ loading at -40 to 75 deg C

MTCTE CERTIFIED

Download the datasheet.

Where to buy

Specification

Download the datasheet.

Ethernet Interface	8 10/100/1000Base-T PoE/ PoE+ ports 2 Combo 10/100/1000 base-T/SFP ports
Switching Method	Store & Forward
MAC Address	8K MAC Address Table
Fast Ring Failover	Rapid Ring Protection Supports STP, RSTP, MSTP
Multicast Support	IGMP v1, v2. MLD v1,v2
VLAN support	802.1q VLAN Port Based VLAN Voice based VLAN Q in Q VLAN
Enclosure	IP-30 certified enclosure
Certifications	Shock: IEC 60068-2-2 Freefall: IEC 60068-2-32 Transportation Industry : NEMA-TS2 CE, FCC, ROHS

Ordering Information

DIS-F200-10PS	8 10/100/1000Base-T PoE/ PoE+ ports & 2 Combo 10/100/1000 base-T/SFP ports Layer 2+ swicth. Operating Temperature -40 to 75 deg C
