Description
The DGS-711 is a high performance 1000BASE-T GBIC transceiver. Supporting full duplex, Gigabit speeds on standard CAT5 UPT cable for a distance up to 100m. The unit features a metal housing to reduce EMI and to increase durability. The DGS-711 is hot pluggable and is backed by a standard 3-year product warranty and free technical support. (Note: The DGS-711 Only Support 1000Mbps Full Duplex)
D-Link's new line of Gigabit Interface Converters (GBICs) and Small Form-Factors Pluggable (SFPs) transceivers represent an industry leading combination of performance and affordability. D-Link's new Gigabit transceivers are available in two form-factors: standard (GBIC) or (SFP)/mini-GBIC.
* Third-Party Devices Must Comply With specified Supported Industy-Standard Specifications
The DGS-711 is a high performance 1000BASE-T GBIC transceiver. Supporting full duplex, Gigabit speeds on standard CAT5 UPT cable for a distance up to 100m. The unit features a metal housing to reduce EMI and to increase durability. The DGS-711 is hot pluggable and is backed by a standard 3-year product warranty and free technical support. (Note: The DGS-711 Only Support 1000Mbps Full Duplex)
D-Link's new line of Gigabit Interface Converters (GBICs) and Small Form-Factors Pluggable (SFPs) transceivers represent an industry leading combination of performance and affordability. D-Link's new Gigabit transceivers are available in two form-factors: standard (GBIC) or (SFP)/mini-GBIC.
* Third-Party Devices Must Comply With specified Supported Industy-Standard Specifications
Specification
Product/Performance Specifications
Data Rate Gigabit
Transmission Range
CAT5
Interface Options
Connector Type
Standards
IEEE
Operational Ranges
Support Voltage
Max Voltage
Max Current
Physical Specifications
Dimensions (WxDxH)
Safety Certifications and Environmental Information
Operating Temperature
Storage
Operating Humidity
Warranty and Support Information
Warranty
Support
Ordering Information
DGS-711
- 1.250Gbps (Bi-Directional)
Transmission Range
CAT5
- 100m
Interface Options
Connector Type
- RJ-45 Type
Standards
IEEE
- 802.3ab
Operational Ranges
Support Voltage
- 3.1-3.5V
Max Voltage
- 6.0V
Max Current
- 300mA
Physical Specifications
Dimensions (WxDxH)
- 1.19x1.0x3.0 in
Safety Certifications and Environmental Information
Operating Temperature
- 0°- 65° C (32° - 149° F)
Storage
- -40° - 70° C (-40° - 158° F)
Operating Humidity
- 10% to 85%
Warranty and Support Information
Warranty
- Limited 3 Year Warranty for as long as the original customer/end user owns the product, (excluding power supplies and fans). Power supplies and fans carry a limited 3 year warranty.
Support
- Free Technical
Ordering Information
DGS-711
- 1000BASE-T CAT5 GBIC -(10Mbps and 100Mbps Speeds Are Not Supported)
FAQ
- $name Read Answer
- $name Read Answer
- $name Read Answer
Support
This product was phased out on: 08/04/2008
This product's last date of support is on: 07/04/2013
Version | Date | Type | File Size | |
---|---|---|---|---|
Datasheet | - | 0.59mb | Download |
