HD PoE Fixed Network Camera

DCS-3010

  • Status produktu: Brak wsparcia

The D-Link DCS-3010 is a full-featured, high-definition, PoE-enabled fixed network camera, equipped with 1/4” megapixel progressive scan CMOS sensor and 4mm fixed iris lens. This camera can capture high resolution videos at resolutions of up to 1280 x 800 with frame rates of up to 30 fps. Snapshots and video can be saved to a network drive, or to onboard storage with the built-in SD card slot.

Multiple Video Streams
The DCS-3010 supports simultaneous streaming of H.264, MPEG-4, and MJPEG video to provide both high-quality and bandwidth-efficient compression formats. MJPEG delivers excellent file integrity, ideal for situations which require high image detail. H.264 and MPEG-4 produce a small file size, useful for extended recording or for use in low-bandwidth networks. Additionally, the DCS-3010 supports multicast H.264 and MPEG-4 streaming, allowing users to view the camera feed by subscribing to a multicast IP address on the network.

Flexible Connectivity
The DCS-3010 incorporates Power over Ethernet (PoE), which allows it to be easily installed in a variety of locations, even when no power outlet is nearby. The DCS-3010 has a built-in microphone as well as external audio input and output, making it useful for remote two-way communication.

A Complete, Expandable Surveillance Solution
The DCS-3010 is a self-sufficient surveillance solution, capable of recording snapshots and videos to a microSD card without requiring a PC or network storage device. If you want to expand your surveillance options, D-ViewCam™ management software is also included, giving you the ability to manage up to 32 cameras with a robust set of features, including multi-camera views and automated e-mail alerts to keep you informed of suspicious or unusual activities

D-ViewCam™ for Management
The included D-Link D-ViewCam™ is sophisticated software which allows users to manage up to 32 network cameras, set e-mail alert notifications, create recording schedules, and use motion detection to directly record important events to a hard drive. D-ViewCam™ also allows users to upload a floor plan to create a realistic layout of the premises where cameras are located, further simplifying the management process.

Open Network Video Interface Forum (ONVIF) Profile S Compliant
ONVIF is an open industry forum for the development of a global standard for the interface of IP based physical security products. ONVIF identifies a standard for how IP products within video surveillance and other physical security areas can communicate with each other ensuring interoperability between products regardless of brand. The DCS-3010 is ONVIF Profile S compliant and therefore interoperable with other manufacturer’s products on the same network such as cameras, storage systems, video analytics products and Video Management Systems. For more information on ONVIF and compatible D-Link network cameras, please click here.

Rodzaj kamery
Wewnętrzna
Połączenie
Power-over-Ethernet
Matryca
1 megapiksel
Przetwornik obrazu
1/4" 1 megapixel progressive scan CMOS
Rozdzielczość
1280 x 720 (16:9)
1280 x 800 (other)
Obiektyw
4 mm
F1.5
stałoogniskowy
Privacy Masks
5 zones
Dwukierunkowe audio
Supported
Wbudowany mikrofon
Supported
External Microphone Input
Supported
External Speaker Output
Supported
External Card Slot
MicroSD SDHC (max 32 GB)
Funkcje
ONVIF
Format wideo
H.264
MJPEG
MPEG-4
Multi-Stream
Supported
Mobile Stream
Supported
Cyfrowe przybliżenie
4x
Wykrywanie ruchu
Supported
Nagrywanie zdarzeń
Supported
Powiadomienia wysyłane na e-mail
Supported
Nagrywanie na rejestrator NAS
Supported
Urządzenie zostało wycofane ze sprzedaży dnia: 13/01/2016
Wsparcie dla produktu skończy się dnia: 12/01/2018
Wersja Data Typ Rozmiar pliku
DCS-3010 datasheet - PDF 1.24mb Pobierz
IP Surveillance Product Guide - PDF 3.58mb Pobierz
Wersja Opis Data Typ Rozmiar pliku
DCS-3010 manual DCS-3010 manual - PDF 6.31mb Pobierz
Wersja Opis Data Typ Rozmiar pliku
1.10 Quick installation guide - PDF 2.32mb Pobierz
Urządzanie D-Link wykorzystuje oprogramowanie innego producenta, wraz z oprogramowaniem bazującym na licencji GNU, tj. Powszechna Licencja Publiczna („GPL”) lub Mniejszej Powszechnej Licencji Publicznej („LGPL”). Warunki działania licencji GPL oraz LGPL wraz z informacjami uzyskania dostępu do kodu GPL oraz LGPL wykorzystanego we wskazanym produkcie, znajdują się tutaj:

http://tsd.dlink.com.tw/GPL.asp

Kod GPL oraz LGPL wykorzystany w produkcie jest rozpowszechniany BEZ ŻADNEJ GWARANCJI i podlega prawom autorskim jednemu lub kilku autorom. Aby dowiedzieć się więcej, zapoznaj się z warunkami licencji GPL oraz LGPL dla tego produktu.
Wersja Opis Data Typ
1.12.18 Release notes included 06.11.2015 - Pobierz
Firmware 1.11.25 1.11.25 Firmware 1.11.25 02.07.2014 - Pobierz
Wersja Opis Data
Device Pack 1.5.4

Device Pack

18.02.2014 Pobierz
D-ViewCam 3.50 + Device Pack 3.60

D-ViewCam 3.50 + Device Pack 1.5.4

18.02.2014 Pobierz
Wersja Opis Data
CE declaration for revison A1 CE declaration for revison A1 14.10.2014 Pobierz
CE declaration for revison A2 CE declaration for revison A2 14.10.2014 Pobierz
IP Surveillance Cheat Sheet IP Surveillance Cheat Sheet 06.06.2014 Pobierz
