Wireless N 5GHz PoE Outdoor Access Point with PoE Pass-Through

DAP-3410

  • Product Status: End of Life

The DAP-3410 is a Wireless N Outdoor Access Point with PoE Pass-Through ideal for expanding wireless coverage or increasing signal strength of any wireless network. Built to withstand harsh environments, the DAP-3410 excels in connecting separate networks that are not joined by a physical cable.

Simplified outdoor connectivity

Low cost Outdoor Access Point, with high power radio design the DAP-3410 is ideal for providing wireless connectivity between two locations.

Broadcast on 8 SSIDs Simultaneously

Supports up to 8 SSIDs per Band that can logically divide the access point into several virtual access points all within a single hardware platform.


Attractive Design

Featuring a clean unobtrusive design, the DAP-3410 can be mounted easily onto any wall or pole. Designed with a PoE pass-through port, the DAP-3410 can also be used to provide power to other devices such as an external camera for added security.

Wireless N mbps Range Single band outdoor


Product Highlights

Durable
Built to withstand harsh outdoor environments and be waterproof to the IPX6 standard

Flexible
PoE powered with PoE pass-through to allow for flexible installation, as well as supply additional power and network connectivity to other PoE powered devices, such as a network camera

Adaptable
With 7 operational modes including access points, WDS, WDS with AP, wireless client, wireless repeater, WISP client router or WISP repeater, the DAP-3410 meets the needs of any situation.

Secure
Secure wireless connectivity using WPA/WPA2 data encryption and MAC address filtering wireless access can be controlled

5Ghz Single-Band Wireless

With a high power radio design and built-in high gain sector antenna,
the DAP-3410 supports up to 300Mbps throughput for the 5Ghz band

Type
Software Managed AP
Wireless standard
Wireless N
Frequency band mode
Single-band
Wireless speed
300 Mbps 5 GHz
Antenna type
Embedded sector antenna
Antenna gain
15 dBi for 5 GHz
Power-over-Ethernet
Yes
Wired interface
2 x Fast Ethernet LAN
Indoor/outdoor
Outdoor
Type of housing
Plastic
IP rating
IPX6
Wireless modes
Access Point (AP)
WDS bridge
WDS with AP
Wireless client
Advanced features
MIMO
Maximum number of SSIDs
8
Auto channel selection
Supported
WMM-PS/802.11e (U-APSD)
Supported
Wi-Fi scheduler
Supported
WEP 64/128 bit
Supported
WPA/WPA2-Personal/Enterprise
Supported
TKIP/AES encryption
Supported
WPA_WPA2_PSK over WDS
Supported
SSID broadcast disable
Supported
Station isolation
Supported
MAC address filtering
Supported
802.1X authentication
Supported
WEB
Supported
SNMP (v1, v2c, v3)
Supported
Telnet
Supported
SSH
Supported
This product was phased out on: 19/11/2016
This product's last date of support is on: 19/11/2018
Version Date Type File Size
Datasheet - PDF 0.50mb Download
Version Description Date Type File Size
Product manual Product manual 15.10.2014. PDF 3.67mb Download
Version Description Date Type File Size
1.10 Quick installation guide 15.10.2014. PDF 0.53mb Download
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:

http://tsd.dlink.com.tw/GPL.asp

The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
Version Description Date Type
Firmware 1.10rc17 Firmware 15.10.2014. - Download
Version Description Date
CE declaration CE declaration 15.10.2014. Download
