Dane techniczne
Physical & Environmental
- Laptop/notebook PC with 32-bit CardBus slot
- 500MHZ processor or above
- 128MB memory or more
- CardBus controller properly installed and working in Win98 SE, ME, 2000, XP computer
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11g
- 32-bit CardBus
- CSMA/CA with ACK
- (With automatic fallback)
- 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps,
- 6Mbps, 5.5Mbps, 2Mbps, 1Mbps
- Orthogonal Frequency Division Multiplexing (OFDM)
- Complementary Code Keying (CCK)
- Direct Sequence Spread Spectrum (DSSS)
- 15 dBm +/- 2dBm
- 54Mbps OFDM, 10% PER, -73dBm
- 48Mbps OFDM, 10% PER, -76dBm
- 36Mbps OFDM, 10% PER, -82dBm
- 24Mbps OFDM, 10% PER, -85dBm
- 18Mbps OFDM, 10% PER, -88dBm
- 12Mbps OFDM, 10% PER, -89dBm
- 11Mbps CCK, 8% PER, -91dBm
- 9Mbps OFDM, 10% PER, -90dBm
- 6Mbps OFDM, 10% PER, -91dBm
- 5.5Mbps CCK, 8% PER, -92dBm
- 2Mbps QPSK, 8% PER, -93dBm
- 1Mbps BPSK, 8% PER, -94dBm
- Diversity switching dual internal antennas
- Indoors: up to 100 meters (328 feet)*
- Outdoors: up to 400 meters (1,312 feet)*
- Environmental factors may adversely affect range
- 64/128-WEP data encryption
- 802.1x authentication
- WPA (Wi-Fi Protected Access): 802.1x, Pre Share Key, WEP, TKIP, AES*
- AES support in software will be released in future upgrade
- Link
- Activity
- Power save mode: 70mW
- Transmit mode: 1650mW
- Standby mode: 1250mW
- 114.3 (L) x 54 (W) x 8.7 (H) mm (4.64 x 2.13 x 0.34 inches)
- 55 grams (0.12 lb.)
- 0o to 55 oC
- 10 o to 60 oC
- 95% maximum (non-condensing)
- FCC Class B
- CE Class B
- C-Tick
- Windows 98 SE, ME, 2000, XP
Wsparcie techniczne
Urządzenie zostało wycofane ze sprzedaży dnia: 16/01/2006
Wsparcie dla produktu skończy się dnia: 16/01/2008
Wersja | Data | Typ | Rozmiar pliku | |
---|---|---|---|---|
Datasheet (English) | - | 0.40mb | Pobierz |
Wersja | Opis | Data | Typ | Rozmiar pliku | |
---|---|---|---|---|---|
Manual (English) | Manual (English) | 27.03.2003 | 2.40mb | Pobierz |
Wersja | Opis | Data | Typ | Rozmiar pliku | |
---|---|---|---|---|---|
Quick installation guide (English) | - | 2.17mb | Pobierz |
Wersja | Opis | Data | |
---|---|---|---|
DEU_Drivers_v2_41_32_RevA | Drivers v2.41.32 | 24.08.2003 | Pobierz |
