Gigabit Managed Switches
DGS-1210/ME Series
- Status produktu (Hardware version: B): W sprzedaży
- Wide range of port configurations
- Advanced layer 2 features with static route and IP interface support
- PoE options up to 370W power budget
- Easy management with web UI
- Available in PoE and non-PoE variations
Lista sklepów
Gigabit Managed Switches
The DGS-1210/ME Series Gigabit Managed Switches provide a diverse range of Gigabit port densities to accommodate various enterprise and public sector connectivity needs. With optional PoE to conveniently power edge devices, SFP ports to extend network connectivity, and advanced Layer 2 functionalities, the DGS-1210/ME Series is ideal for any enterprise access layer or large multi-site deployment and allows businesses to build a more secure and efficient network with advanced network security features and QoS.
Elastyczna konstrukcja
Szeroki zakres portów i typów mediów, w tym porty 10/100/1000 BASE-T RJ- 45, porty combo 100/1000 Mb/s GbE/SFP oraz porty SFP 100/1000 Mb/s.
Wysoka wydajność przełączania i budżet PoE
Możliwość przełączania do 104 Gb/s przy maksymalnym budżecie PoE do 370W.
Warstwa 2 z funkcjami warstwy 3
Kompletny zestaw funkcji warstwy 2 oraz obsługa interfejsów IP, ARP, protokół IPv6 neighbor discovery (ND) i domyślny routing.
Bezpieczeństwo sieci
Innowacyjny Safeguard Engine™ D-Linka zapewnia bezpieczeństwo sieci i chroni przełączniki przed złośliwymi atakami.
Uproszczone zarządzanie
Ułatwione korzystanie dzięki wsparciu D-Link Network, narzędzi interfejsu użytkownika oraz CLI za pośrednictwem protokołów Telnet lub SSH.
Gwarancja Limited Lifetime
Zarejestruj produkt, aby skorzystać z dożywotniej gwarancji Lifetime Limited
Gigabit Performance
The DGS-1210/ME Series Gigabit Managed Switches come in a variety of port setups, including Gigabit Ethernet RJ-45 and SFP ports. The DGS-1210-10P/ME, DGS-1210-28P/ME and DGS-1210-52MP/ME switches feature Power over Ethernet (PoE), allowing compatible devices to be installed and powered in remote locations without immediate access to power outlets.
Efficient and Resilient Networking
For mission critical environments, the DGS-1210/ME Series Gigabit Managed Switches support IEEE 802.1D 2004 edition, 802.1w, and 802.1s Spanning Tree Protocols (STP). The Spanning Tree Protocol allows the switches to participate in Spanning Tree topology, providing an alternative Layer 2 path in the event of a network failover. The switches also support IEEE 802.3ad link aggregation, which enables multiple ports to be grouped to form a single virtual port, increasing bandwidth and redundancy for higher availability. This series furthermore features IEEE 802.1p Quality of Service (QoS), allowing for real-time traffic classification into Weighted Round Robin (WRR) and strict priority levels mapped to 8 queues. Advanced traffic classification parameters allow the network to be tuned for flexible configurations for specific multimedia applications such as VoIP or IPTV.
Multicast Applications
The DGS-1210/ME Series features a full set of L2 multicast functions, including IGMP snooping, IGMP filtering, fast leave, and multicast traffic configuration for specific ports. With L2 multicast support, the DGS-1210/ME Series is ready and capable of handling growing IPTV applications. Host-based IGMP/MLD snooping allows for multiple multicast subscribers per physical interface, and ISM VLAN sends multicast streams in a multicast VLAN, saving bandwidth on the backbone. Additionally, ISM VLAN profiles allow users to bind or replace the predefined multicast registration information to subscriber ports quickly and easily.
Traffic & Bandwidth Control
Integrated bandwidth control allows network administrators to define the throughput levels for ingress and egress bandwidth. It provides a minimum granularity of 64 Kbps for ingress port and flow-based bandwidth control, and a minimum granularity of 64 Kbps for egress queue bandwidth. The DGS-1210/ME Series also supports traffic control, which optimizes performance by dropping packets when exceeding a set threshold, while port mirroring helps administrators facilitate traffic diagnostics and track network performance. The DGS-1210/ME Series also provides IGMP snooping with IGMP authentication to prune multicast traffic and to optimize available bandwidth.
Management Capabilities
A user-friendly web interface gives administrators access to advanced management features such as DHCP auto-configuration. This enables switches to load their configuration from a TFTP server once they have been assigned an IP address, allowing central management of device configurations. The switches support Link Layer Discovery Protocol (LLDP), which advertises the device’s capabilities and identity to the local network, allowing administrators to better manage their network topology. Each port also supports cable diagnostics, which can be used to troubleshoot cable length and functionality problems remotely, resulting in lower management overheads.
Security & Authentication
The DGS-1210/ME Series supports IEEE 802.1X port-based/host-based access control, guest VLAN, and RADIUS/TACACS+ authentication for strict access control to the network. The IP-MAC-Port Binding (IMPB) feature allows administrators to associate a source IP address with a designated MAC address and also offers the flexibility to define the port number to enhance user access control. The built-in D-Link Safeguard Engine™ protects the CPU from broadcast, multicast, and unicast flooding by automatically trapping packets and logging events in these situations. In addition, the Access Control List (ACL) feature enhances network security and switch performance.
Bezpłatna usługa Next-Business-Day (NBDS)
Skorzystaj z naszej bezpłatnej usługi Next Business Day dedykowanej rozwiązaniom biznesowym, aby szybko wymienić uszkodzony sprzęt.
Ponad 35 lat doświadczenia
Innowacyjne, kompleksowe rozwiązania dla małych i średnich przedsiębiorstw jak również użytkowników domowych.
Porozmawiajmy
Wykwalifikowane wsparcie lokalne w 16 krajach. Nasze zespoły wsparcia są gotowe, aby Ci pomóc.
Dożywotnia gwarancja Lifetime-Limited
Zapewniamy dożywotnią gwarancję Lifetime-Limited dla urządzeń D-Link. Wymagana jest rejestracja produktu.
Sugerowane urządzenia
Dane techniczne
|
Liczba portów
|
16 - 28 portów 48 - 52 porty 5 - 10 portów |
|---|---|
|
Warstwa
|
Layer 2+ |
|
Rodzaj portów
|
1000BASE-T Gigabit Ethernet |
|
Rodzaj portów uplink
|
SFP |
|
Przepustowość przełączania
|
104 Gbps 20 Gbps |
|
Standard PoE
|
802.3af 802.3at |
|
Liczba portów PoE
|
24 48 |
|
Budżet PoE
|
0 do 100W 101 do 200W 201 do 400W |
|
D-Link Green
|
Supported
|
|
802.3az Energy-Efficient Ethernet support
|
Supported
|
|
Montaż
|
Szafa Rack |
|
Obudowa
|
Metal |
|
Ramki Jumbo
|
Supported
|
|
Diagnostyka kabla
|
Supported
|
|
MAC address
|
16K |
|
Spanning Tree Protocol
|
802.1D STP 802.1s MSTP 802.1w RSTP |
|
Agregacja linków
|
802.3ad |
|
VLAN group (max static)
|
4K |
|
Typ VLAN
|
GVRP w oparciu o adresację MAC w oparciu o port w oparciu o protokół |
|
Advanced VLAN
|
Asymmetric VLAN Double VLAN (Q-in-Q) ISM VLAN |
|
IPv6 Ready
|
Supported
|
|
Liczba kolejek QoS na port
|
8 |
|
CoS na podstawie zawartości
|
Supported
|
|
Kontrola przepustowości
|
64 Kbps minimum granularity |
|
Typ ACL
|
Ingress |
|
ACL based on packet contents
|
Supported
|
|
Time-based ACL
|
Supported
|
|
Encryption protocol supported
|
SSH SSL (v1/v2/v3) |
|
IP-MAC-port binding (IMPB) / Smart Binding
|
Supported
|
|
ARP spoofing
|
Supported
|
|
BPDU attack protection
|
Supported
|
|
Kontrola dostępu 802.1X
|
Supported
|
|
Microsoft NAP support
|
Supported
|
|
Uwierzytelnienie RADIUS/TACACS+
|
Supported
|
|
SNMP (v1/v2c/v3)
|
Supported
|
|
RMON v1/v2
|
Supported
|
|
LLDP
|
Supported
|
|
ICMPv6
|
Supported
|
