Flexibilität ohne Kompromisse
Der Access Point bietet 300 Mbit/s WLAN-Leistung und ist vielseitig in unterschiedlichen Bereichen einsetzbar.

Übertragung mit 8 SSIDs gleichzeitig
Der Access Point unterstützt bis zu 8 SSIDs je Frequenzband, mit denen er logisch in mehrere virtuelle Access Points auf einer Hardware-Plattform aufgeteilt werden kann.

Zuverlässige WLAN- und Maximal-Übertragungsraten
Der DAP-2360 setzt auf eine einzelne Hochleistungsfunkeinheit, um Funklöcher zu beseitigen und die WLAN-Kapazität zu erhöhen, damit Netzwerkadministratoren hervorragend steuerbare und äußerst belastbare WLANs bereitstellen können.






WLAN-Geschwindigkeit von bis zu 300 Mbit/s

Sicheres und umweltfreundliches Design
Der DAP-2360 besitzt eine Zeitschaltfunktion, die das WLAN abschaltet, wenn es nicht benötigt wird. So wird Energie gespart und die Netzwerksicherheit verbessert.

Kostenlose Controller-Software für WLAN-Access-Points
Central WiFiManager von D-Link ist ein kostenloses cloudfähiges Managementtool für WLAN-Access-Points. Damit können Sie drahtlose Netzwerke an mehreren Standorten und mit Multi-Tenant-Strukturen aufbauen und verwalten.

Bis zu 1000 APs verwalten
Managen Sie mit einem virtuellen Controller weltweit bis zu 1000 Access Points in Ihrem Netzwerk oder in der Cloud.

Skalierbares, flexibles und zentrales AP-Management
Verwalten Sie zentral bis zu 1000 APs, unabhängig von deren Standort.

Produktvergleich
<>Wireless N
![]() |
![]() |
![]() |
||
---|---|---|---|---|
DAP-2310 | DAP-2360 | DAP-2690 | ||
Wireless Standard | B, G, N | B, G, N | B, G, N | |
Frequency | 2.4GHz | 2.4GHz | 2.4GHz, 5GHz | |
2.4GHz Throughput | 300Mbps | 300Mbps | 300Mbps | |
5GHz Throughput | - | - | 300Mbps | |
Aspect | Indoor | Indoor | Indoor | |
Range* | 100m | 100m | 100m |
<>Wireless AC
![]() |
![]() |
|||
---|---|---|---|---|
DAP-2660 | DAP-2695 | |||
Wireless Standard | B, G, N, AC | B, G, N, AC | ||
Frequency | 2.4GHz, 5GHz | 2.4GHz, 5GHz | ||
2.4GHz Throughput | 300Mbps | 300Mbps | ||
5GHz Throughput | 867Mbps | 1300Mbps | ||
Aspect | Indoor | Indoor | ||
Range* | 100m | 100m |
* Range indicates the maximum distance where the highest throughput can be achieved, anything beyond this distance results in a loss of throughput.
Weitere Produkte





Specs
Type
|
Software Managed AP |
---|---|
Wireless standard
|
Wireless N |
Frequency band mode
|
Single-band |
Antenna type
|
2 detachable omni-directional antennas |
Antenna gain
|
5 dBi for 2.4 GHz |
Power-over-Ethernet
|
Yes |
Wired interface
|
1 x Gigabit Ethernet LAN |
Indoor/outdoor
|
Indoor |
Type of housing
|
Metal |
Plenum rated (UL-2043)
|
Supported
|
Wireless modes
|
Access Point (AP) WDS bridge WDS with AP Wireless client |
Advanced features
|
MIMO |
Maximum number of SSIDs
|
8 |
Auto channel selection
|
Supported
|
WMM-PS/802.11e (U-APSD)
|
Supported
|
Wi-Fi scheduler
|
Supported
|
AP traffic load balance
|
Supported
|
L2 roaming
|
Supported
|
WEP 64/128 bit
|
Supported
|
WPA/WPA2-Personal/Enterprise
|
Supported
|
TKIP/AES encryption
|
Supported
|
WPA_WPA2_PSK over WDS
|
Supported
|
WLAN partition
|
Supported
|
SSID broadcast disable
|
Supported
|
Rogue AP detection
|
Supported
|
Station isolation
|
Supported
|
MAC address filtering
|
Supported
|
802.1X authentication
|
Supported
|
DHCP server
|
Supported
|
802.1D STP
|
Supported
|
IGMP snooping
|
Supported
|
ARP spoofing
|
Supported
|
NTP
|
Supported
|
IPv6
|
Supported
|
Management platform
|
Central WiFiManager (CWM-100) |
WEB
|
Supported
|
SNMP (v1, v2c, v3)
|
Supported
|
CLI
|
Supported
|
Telnet
|
Supported
|
SSH
|
Supported
|
Syslog
|
Supported
|
Central management (through AP Manager II and/or D-View Wireless Control Module)
|
Supported
|
