Using the latest generation of Wireless N technology, the DAP-2553 delivers great wireless performance and coverage in a compact design.
Supporting up to 4 different operating modes, the DAP-2553 is one of the most flexible access points on the market.
With it’s deceptively small and simple design, the DAP-2553 is a robust and versatile access point. Multiple operational modes mean it can be deployed quickly and efficiently in any environment.
Supports up to 300Mbps for the 5Ghz band or up to 300Mbps for the 2.4Ghz band
The DAP-2553 has a wireless scheduler feature, which turns off wireless functionality when it isn’t needed, saving power and increasing network security.
|
Type
|
Software Managed AP |
|---|---|
|
Frequency band mode
|
Dual-band selectable |
|
Wireless standard
|
Wireless N |
|
Advanced features
|
MIMO |
|
Antenna type
|
3 detachable omni-directional antennas |
|
Antenna gain
|
3 dBi for 2.4 GHz 5 dBi for 5 GHz |
|
Power-over-Ethernet
|
Yes |
|
Wired interface
|
1 x Gigabit Ethernet LAN |
|
Indoor/outdoor
|
Indoor |
|
Type of housing
|
Plastic |
|
Wireless modes
|
Access Point (AP) WDS bridge WDS with AP Wireless client |
|
Maximum number of SSIDs
|
4 |
|
Auto channel selection
|
Supported
|
|
WMM-PS/802.11e (U-APSD)
|
Supported
|
|
Wi-Fi scheduler
|
Supported
|
|
AP traffic load balance
|
Supported
|
|
L2 roaming
|
Supported
|
|
WEP 64/128 bit
|
Supported
|
|
WPA/WPA2-Personal/Enterprise
|
Supported
|
|
TKIP/AES encryption
|
Supported
|
|
WPA_WPA2_PSK over WDS
|
Supported
|
|
WLAN partition
|
Supported
|
|
SSID broadcast disable
|
Supported
|
|
Rogue AP detection
|
Supported
|
|
Station isolation
|
Supported
|
|
MAC address filtering
|
Supported
|
|
802.1X authentication
|
Supported
|
|
DHCP server
|
Supported
|
|
802.1D STP
|
Supported
|
|
IGMP snooping
|
Supported
|
|
NTP
|
Supported
|
|
WEB
|
Supported
|
|
SNMP (v1, v2c, v3)
|
Supported
|
|
CLI
|
Supported
|
|
Telnet
|
Supported
|
|
SSH
|
Supported
|
|
Syslog
|
Supported
|
|
Central management (through AP Manager II and/or D-View Wireless Control Module)
|
Supported
|
