2.5G L3 Stackable Managed 核心/匯聚可堆疊網管PoE交換器

DMS-3130-30PS

16 x 100M/1/2.5GBASE-T PoE+ ports + 8 x 100M/1/2.5/5GBASE-T PoE++ ports
2 x 100M/1/2.5/5/10GBASE-T ports and 4 x 10/25G SFP28 ports provide all the uplink capacity your network needs
PoE budget of 740W allows powering of numerous external devices (Up to 960W with dual powers)
Premium L2 and L3 features effortlessly improve network efficiency and reduce unnecessary data transfer
RIP/RIPngand OSFPv2/v3 dynamically map out your network, aiding data to get to its destination via the fastest route possible
Expand capacity in a flash with physical stacking up to 9 units
Smart Fan self-adjusts accordingly to maintain optimal operating temperatures
Support ERPS, Q-in-Q and 6 KV surge protection
Support 60W PoE compliancewith IEEE 802.3bt
Perpetual PoE and Fast PoE support delivers faster and uninterrupted power to connected devices even when the switch is booting

Where to buy

DMS-3130-30PS

Find out more

2.5G L3 Stackable Managed 核心/匯聚可堆疊網管交換器

DMS-3130-30TS

Find out more

PoE Ports	2 x 100M/1/2.5/5/10GBASE-T ports 4 x 10/25G SFP28 ports 8 x 100M/1/2.5/5GBASE-T 60W PoE ports 16 x 100M/1/2.5GBASE-T PoE ports
Optional Redundant Power Supply	AC (DPS-PWR740AC) hot-swappable internal redundant power supplies DC (DPS-PWR740DC) hot-swappable internal redundant power supplies
Console Port	10/100/1000BASE-T RJ-45 port for out-of-band CLI management
RJ-45 Management Port	10/100/1000BASE-T RJ-45 port for out-of-band IP management
Performance	64 Byte Packet Forwarding Rate 298 Mpps Packet Buffer Memory 4 MB
Interfaces	1 x Stacking Cost 4 x Stacking Ports 1 x USB 2.0 Type A port
Switching Capacity	400 Gbps
Standards	IEEE 802.3af IEEE 802.3at IEEE 802.3bt
PoE Power Budget	740 W 960 W (dual power supplies)
實際效能可能因設定、線纜、溫度、網路配置、介面、設備相容性、環境和現場條件以及其他類似因素而有所不同。有關功率、訊號或處理速度、訊號範圍或距離、資料加密、儲存容量、顯示特性或其他效能指標的說明均基於業界標準得出的最佳條件，僅供參考。規格如有變更，恕不另行通知。
