Disponibile solo per progetti
Switch a chassis managed con 10 slot per schede e supporto layer 2/3+
- DES-7206
- 2 slot riservati per doppio modulo di controllo ( secondo modulo opzionale utilizzabile per la condivisione del carico / ridondanza dello switch fabric)
- 4 slot per moduli porte
- 2 slot per l'utilizzo di due alimentatori ( soluzione ridondanta )
- Cassetto gruppo ventole estraibile
- Switch fabric fino a 192 Gbps
- Capacità si inoltro dei pacchetti fino a 142 Mpps
- Installabili fino a 192 porte Gigabit
- Utilizzabii fino a 8 porte 10 Gigabit
n.b. alimentatore non incluso
Prodotti correlati
Specifiche tecniche
|
Layer
|
Layer 3 |
|---|---|
|
Main type of ports
|
1000BASE-T Gigabit Ethernet SFP |
|
Number of ports
|
100 to 200 ports |
|
Type of uplink ports
|
Combo 1000BASE-T/SFP SFP 10GbE XFP |
|
Switching capacity
|
192 Gbps |
|
Form Factor
|
Chassis-based |
|
MAC address
|
16K 32K |
|
Spanning Tree Protocol
|
802.1D STP 802.1s MSTP 802.1w RSTP |
|
Ethernet ring protection switching (ERPS)
|
Supported
|
|
Link aggregation
|
802.3ad |
|
VLAN group (max static)
|
4K |
|
VLAN type
|
Port-based Protocol-based |
|
Advanced VLAN
|
Super VLAN Double VLAN (Q-in-Q) |
|
IPv4/IPv6 routing table
|
IPv4 - 12K IPv6 - 6K IPv4 - 192K IPv6 - 96K |
|
IP interfaces
|
2000 |
|
IPv6 Ready
|
Supported
|
|
IPv6 tunneling
|
Supported
|
|
Multicasting
|
Supported
|
|
PIM-SM
|
Supported
|
|
RIP v1/v2
|
Supported
|
|
OSPF
|
Supported
|
|
BGP
|
Supported
|
|
OSPFv3
|
Supported
|
|
MPLS
|
Supported
|
|
Number of QoS queues per port
|
8 |
|
CoS based on contents
|
Supported
|
|
Bandwidth control
|
64 Kbps minimum granularity |
|
ACL type
|
Ingress VLAN-based |
|
ACL based on packet contents
|
Supported
|
|
Time-based ACL
|
Supported
|
|
Encryption protocol supported
|
SSH |
|
IP-MAC-port binding (IMPB) / Smart Binding
|
Supported
|
|
802.1X access control
|
Supported
|
|
RADIUS/TACACS+ authentication
|
Supported
|
|
SNMP (v1/v2c/v3)
|
Supported
|
|
RMON v1
|
Supported
|
|
Le prestazioni effettive possono variare in base alle impostazioni, al cablaggio, alla temperatura, alla configurazione della rete, all’interfaccia, alla compatibilità dei dispositivi, alle condizioni ambientali e operative in loco e ad altri fattori simili. I riferimenti alla capacità di alimentazione, alla velocità del segnale o di elaborazione, alla portata o distanza del segnale, alla cifratura dei dati, alla capacità di archiviazione, alle proprietà del display o ad altri parametri prestazionali si basano su condizioni ottimali derivate da standard del settore e sono forniti esclusivamente a scopo informativo. Le specifiche possono essere soggette a modifiche senza preavviso. |
|
Supporto
| Versione | Data | Tipo | Dimensioni file | |
|---|---|---|---|---|
| DES-7200 Series datasheet | - | 1.11mb | Download |
| Versione | Descrizione | Data | Tipo | Dimensioni file | |
|---|---|---|---|---|---|
| DES-7200 Series hardware installation guide | DES-7200 Series hardware installation guide | - | 3.48mb | Download | |
| DES-7200 Series configuration guide | DES-7200 Series configuration guide | - | 15.22mb | Download | |
| DES-7200 Series CLI reference guide | DES-7200 Series CLI reference guide | - | 5.71mb | Download |
| Versione | Descrizione | Data | Tipo | |
|---|---|---|---|---|
| DES-7200 Series firmware 10.4(3) | DES-7200 Series firmware | - | - | Download |
