DWR-730

Product Status - Live

Downloads can vary across product revisions. Please select the correct hardware revision.

Features

Connectivity

  • Uses a USIM card to connect to the Internet
  • 802.11b/g certified, and compatible with 802.11n devices
  • microSD card slot to access your storage3
  • USB 2.0 port for easy charging

Portability

  • Up to six hours of battery life in one charge so you can stay connected for longer
  • Small size lets you drop it in a purse or pocket and take it wherever you go

OLED Display

  • Stay informed with the built-in OLED display
  • Real-time status of your 3G Internet connectivity and signal as well as battery, SMS messages and number of devices connected.

Security

  • WPA/WPA2 Wi-Fi security protocols provide the latest in wireless security
  • Built-in firewall keeps unwanted connections out
  • Wi-Fi Protected Setup (WPS) for one-touch secure setup with other devices

Share

  • Fast broadband download speeds
  • Share files over Wi-Fi using SAMBA technology

Compatibility

  • Works with different OS platforms including MacOS, Windows, and Linux

Technical Specifications

General

GSM/GPRS/EDGE band

  • Quad-Band : 850/900/1800/1900 MHz
  • Power Class 4 (+33 dBm, 850/900 MHz)
  • Power Class 1 (+30 dBm, 1800/1900 MHz)

UMTS/HSDPA/HSUPA1 band

  • 900/2100 MHz
  • 850/1900/2100 MHz
  • AWS/850/1900 MHz
  • Power Class 3 (+23 dBm)

Data Throughput2

  • Downlink up to 21.6 Mbps in HSPA+ mode
  • Uplink up to 5.76 Mbps in HSPA+ mode

Security

  • WEP 64-bit/128-bit
  • WPA-PSK Auto(TKIP/AES)
  • WAP2-PSK Auto (TKIP/AES)
  • WPS Push-Button Connection

Advanced Functions

  • Built-in firewall
  • Built-in NAT
  • UPnP
  • File sharing via Wi-Fi (SAMBA)
  • DLNA

Physical/Interfaces

Interfaces

  • 802.11b/g wireless LAN, compatible with 802.11n devices
  • 6-pin USIM card interface
  • microSD card interface
  • Micro-USB port

Antenna

  • 1 x internal 3G main antenna
  • 1 x internal Wi-Fi antenna
  • 1 x internal 3G auxiliary antenna (on band 900/2100 or 850/1900/2100)

Display

  • Network type
  • Signal strength
  • Roaming status
  • SMS & SMS status
  • Internet connection status
  • Carrier
  • Battery status
  • Wi-Fi & security status
  • Wi-Fi clients

Power

  • DC 5 V/1 A +/- 5%
  • 2000 mAh Li-ion battery

Dimensions

  • 103.3 x 51.5 x 13.5 mm (4.07 x 2.03 x .53 in)

Weight

  • 77 g (.17 lb)

Operating Temperature

  • -10 to 55 ˚C (23 to 131 ˚F)

Operating Humidity

  • 10% to 90% (non-condensing)

Certifications

  • CE
  • FCC

1 Supported frequency band is dependent upon regional hardware version.
2 Data rates are theoretical. Data transfer rate depends on network capacity and signal strength.
3 SD card not included.
