5埠 Fast Ethernet 快速乙太網路桌上型無網管交換器

DES-1005C / Cx

  • Product Status: Live
  • 5 x 10/100Mbps 自動速率偵測
  • 具LED指示燈 無風扇靜音設計
  • 隨插即用 體積輕巧 智慧節能
  • 內建MDI/MDIX自動跳線 及流量控制
Where to buy

數位時代來臨，高效能首選

DES-1005C為經濟實用的桌上型網路交換器，特別適用於 數位家庭、租屋、SOHO 、中小辦公、空間區隔、連鎖街邊店、門市超商等多功能環境，本款提供10/100Mbps 快速乙太網路傳輸速率選擇，隨插即用輕鬆擴充網路架構，快速升級連線效能。

經濟實惠，高興價比的選擇

The DES-1005C 10/100 Mbps Unmanaged Switch is an economical, plug-and-play networking switch for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Fast Ethernet. It gives you five 10/100 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity.

友善環境，綠色節能

The DES-1005C implements 802.3az Energy Efficient Ethernet, which saves energy and reduces heat automatically without sacrificing performance or functionality. The switches can detect when a connected computer is shut down or when there is no Ethernet traffic, and will put the port in standby mode, saving a substantial amount of power. In addition, the switch optimizes power usage for each port for the length of cable connected to it, using only as much power as is required. Both of these features work together to help you save power automatically.

隨插即用，輕鬆安裝上手

The DES-1005C is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. 802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.

產品規格

Interfaces
5 x 100Base-TX
Auto MDI/MDIX
Yes
Switching Capacity
1 Gbps
Max. Packet Forwarding Rate
0.74 Mpps
Store & Forwarding Forwading
Yes
Dimensions
88x48x21.45mm
Weight
434 g
Operating Temperature
0 ~ 40 °C
Storage Temperature
- 40 ~ 70 °C
Operating Humidity
10% ~ 90% RH
Storage Humidity
5% ~ 95% RH
Maximum Power Consumption
0.784 W
Standby Power Consumption
0.4 W
Maximum Heat Dissipation
0.406 BTU/h
MTBF
1,785,631 hours
Power Input
DC: 5V, 0.55A
Packet Buffer Size
96KBytes
FAN
Fanless
Energy Efficiency Ethernet (EEE)
Yes
Power Saving By Link Status
YES
MAC Address Table Size
2,000
Control
802.3x Flow
Head-of-line (HOL) Blocking Prevention
Yes
Jumbo Frame
2048 Bytes

實際效能可能因設定、線纜、溫度、網路配置、介面、設備相容性、環境和現場條件以及其他類似因素而有所不同。有關功率、訊號或處理速度、訊號範圍或距離、資料加密、儲存容量、顯示特性或其他效能指標的說明均基於業界標準得出的最佳條件，僅供參考。規格如有變更，恕不另行通知。
