D-View SNMP Network Management System Standard Edition


  • Product Status (Revision A): End of Life

Ideal for Layer 2 device monitoring, the D-View® SNMP Network Management System provides useful tools to allow users to effectively manage device configurations.

D-View 5.1 SNMP Network Management System is a comprehensive standards-based management tool designed to centrally manage critical network characteristics such as availability, responsiveness, resilience and security in a consistent way. Flexible and versatile, this software accommodates a wide range of new D-Link and third-party devices, including wireless bridges and access points, multi-layer switches, remote routers, and multi-tenant broadband CO devices. D-View provides useful tools to allow you to effectively manage device configurations, fault tolerance, performance, security and accounting services.

Modular Architecture

D-View is organized into a vendor-independent platform and user plug-in modules. The platform consists of five main components, namely the Alarm/Trap Manager, Discovery/Parsing, MIB utilities, Internet tools, and the User Account Manager.

Managing Third-party Devices

The user can manage non-D-Link SNMP devices without plug-in modules. D-View provides a MIB compiler for the user to compile MIB files from the vendor of the device into a system-recognized format, then loads it into a database. The compiler can communicate with the user’s network device to get the current values or to set new values for the MIB objects of the user’s interest. All MIBs are converted into a graphic tree view, which can use the MIB Browser to manage the device.

Microsoft Access Format Database

MIB contents in the database generated by the MIB compiler are organized according to the Microsoft Access format. This enhances the integration of the user’s environment, while giving the user the options of editing the user’s database using D-View or the familiar Microsoft Access software.

User Account Management & Billing System

User account management can be used with devices like wireless broadband gateways and multi-tenant broadband switches to provide connection to paying customers. This accounting system can be incorporated into the customer’s equipment.

A simple billing system offers services in connection with user account management. The features include assignment of account with personal authorization IP address for each client; generation of statements with different schedules for different groups of clients; detection of abnormal usage for clients; assignment of custom taxes to service charges; credit adjustment function to let the user insert credit records manually and give credit for wrong or misdialed works; late fee assessment function; real-time reporting for current client summary, credit limit status report, and payment report.

D-Link DS-510S Benefit Summary

D-View supports a modular architecture, which allows users to install a module for various network devices into the system. D-View allows users to analyze and to manage such device upon the module installation. In addition, the Module Wizard can be used to compile and store the MIB file into the database if the user does not possess the device module. D-View is also able to manage a network device through the MIB Browser.

D-View supports many standard MIB utilities such as MIB II, 802.1D, 802.1p, 802.1Q, RMON group, OSPF, DVMRM, PIM, IPM, RIP1, and RIP2.

D-View 5.1 is an affordable but professional network management software. The user can easily use it to manage the corporate network routinely and use its advanced functions in Professional Version to do more complex and advanced management.
System Requirements
  • CPU: 550 Mhz or above
  • DRAM: 256MB
  • Hard drive available space: 100MB
  • Ethernet adapter: 10/100BASE-TX
  • Operating System: Windows 2000 or Windows XP
  • Access 2000 software

MIB Utilities
  • Device SNMP Configuration *
  • MIB II Information and Statistics Windows
  • IF MIB Information Tables
  • Entity MIB Information Tables
  • Bridge 802.1d Information and Port Configuration Table
  • Spanning Tree Information and Port Configuration Table
  • Transparent Bridge Forwarding and Static Filter Tables and Port Counter
  • RMON Statistics, History and Event Windows
  • 802.1p Priority Configuration including GMRP and GARP *
  • 802.1Q VLAN Information and Configuration including
  • Forwarding/Filtering and Unicast/Multicast Configuration *
  • Port VLAN Traffic Statistics *
  • Layer 3 Utilities including IP Forwarding, RIP2, OSPF, IP Multicast, DVMRP and PIM Configuration *
  • SNMP Configuration *

Configuration Management Functions
  • MIB utilities
  • MIB Compiler
  • MIB Browser
  • Web configuration
  • DIAP tools
  • TFTP file transfer
  • Bootp
  • Ping

Fault Management Functions
  • Trap log
  • Trap filter
  • Trap mail
  • Trap editor
  • Message log
  • Ping
  • Alarm mail interval

Performance Management Functions
  • RMON
  • 802.1d bridge
  • Port counter
  • VLAN *
  • Traffic statistics
  • RIP-2 routing *
  • DVMRP interface table *

Security Management Functions *

SNMP v3 covers security functions such as packet encryption/decryption, user levels for different classes of access right, MPD (RFC 2572), TARGET (RFC 2573), USM (RFC 2574) user-based security level, VACM (RFC 2575) view-based access control.
  • Device SNMP configuration
  • SNMP v3 configuration

Accounting Management Functions *
  • Client information update
  • Freeze/unfreeze client connection
  • Client record query
  • Client On-line query
  • Client abnormal situation
  • Device utilization
  • Pay Rate Configuration

Supported D-Link Devices
  • Managed 10/100Mbps & Gigabit L2, L3 switches
  • Remote routers
  • Wireless Access Points & bridges
  • VDSL switches

Supported 3rd-Party Devices
  • ATI Hub
  • Cisco 760 Router, 1600 Router, 2500 Router, Catalyst 2900  series
  • HP 28xxA switch, Switch 200, Switch 16, Router 200/400/  600 series, 286xx Hub, J2355A
  • Nortel/Wellfleet Router
  • Microsoft NT

Ordering Information

  • D-View SNMP Network Management Program

Please specify your order as follows:

  • Professional version

  • Standard version

* Functions available in Professional Version only
This product was phased out on: 16/06/2009
This product's last date of support is on: 15/06/2014
