Smart+ Managed Gigabit Switches
DGS-1210 Series
- Product Status (Hardware version: Fx): Live
- Funções Advanced Layer 2 e Layer 3 Static Routing
- Gestão mediante Command Line Interface (CLI), Web GUI e Nuclias Connect
- Routing estático e MSTP
- Opções PoE, PoE+ e Uplinks fibra ótica
- Dual image & Dual config files
- Garantía limitada vitalicia após registo do produto
- Novidade! Integra-se com o software Nuclias Connect (DNC-100) para gestão integral com pontos de acesso D-Link DAP Nuclias Connect
Where to buy
![](/pt/pt/-/media/product-pages/common/product-features/2018/static-routing.png)
Static Routing
Route Layer 3 traffic between switches, even if they're segmented in VLANs.
![](/pt/pt/-/media/product-pages/common/product-features/2018/uplink.png)
Fibre Uplink Ports
Connect to other areas of your network at fibre-optic Gigabit speeds, and reach even further distances.
![](/pt/pt/-/media/product-pages/common/product-features/2018/surveillance-mode.png)
Surveillance Mode Interface
D-Link’s exclusive, easy-to-use Surveillance Mode interface gives you a snapshot of your security topology in an instant.
PoE Capable
Up to 370 W PoE output per switch
![](/pt/pt/-/media/product-pages/common/product-features/2018/static-routing.png)
VLANs
Segment your network into VLANs.
![](/pt/pt/-/media/product-pages/dgs/3130/assets/dgs3130_icon_08_dualimage.png)
Dual Image
Risk-free configuration testing.
Promoção B2B
Descontos* até 51% para redes empresariais
A promoção oferece soluções versáteis para qualquer necessidade ou orçamento com incríveis descontos
- Switches Power Over Ethernet (PoE) sem gestão para alimentação e dados através do mesmo cabo de rede, ideais como switches de extremidade.
- Switches administrados, DGS-1210, de 8 a 52 portas Gigabit, com uplinks de fibra e várias opções PoE. Gestão completa L2 e L3 com routing estático. Gestão através de GUI Web ou gestão unificada com pontos de acesso Wi-Fi no software gratuito D-Link Nuclias Connect.
- Pontos de acesso Wi-Fi, projetados para alta densidade de utilizadores, com Fast Roaming. Gestão unificada com os Switches DGS-1210 na plataforma gratuita Nuclias Connect.
Se já é parceiro do Programa de Canal VIP+ da D-Link pode descarregar a promoção acedendo ao portal VIP+ aqui.Se é revendedor ou instalador profissional pode registar-se em VIP+ sem custos neste link, pedir informação no chat B2B desta página ou mandar um email aqui.
Descubra todos os produtos incluidos e os descontos* nesta ligação.
*Promoção exclusiva de canal profissional para revendedores e parceiros do Programa de Canal VIP+ da D-Link.
Válida até 30 de Setembro de 2024. Não é válida para cliente final
![](/pt/pt/-/media/images/es/promos/dlinkpromoncq124webtextmedia750.jpg?h=630&w=750&la=pt-PT&hash=B193FF04E0C08B44DD17186B790F4AF3)
Gestão Unificada gratuita
Nuclias Connect (DNC-100) é o software gratuito de gestão unificada de Pontos de Acesso Wi-Fi das famílias DAP e Switches Smart Managed da gama DGS-1210*
- Gestão centralizada de Pontos de Acesso e Switches desde a web e/ou app gratuita, sem custos nem licenças.
- Wireless: Análise de tráfego, gestão de RF e canais, portal cativo, SSIDs, etc.
- Switching: Gestão de portas, segmentação com VLANs, listas de controle de acesso, Spanning Tree, etc.
- Instalável em Windows ou Linux. Opção controladora física com custo (DNH-100)
- Fácil descobrimento em layer 2/3 de Pontos Acesso e Switches.
- Aprovisionamento em bloco de múltiplos pontos de acesso com móvel desde a app (iOS/Android)
*Requer instalar a última versão de Nuclias Connect (1.2.0.5). Switches compatíveis (após atualizar o seu firmware)
DGS-1210-10, DGS-1210-10P, DGS-1210MP, DGS-1210-20, DGS-1210-26, DGS-1219-28, DGS-1210P, DGS-1210-28MP, DGS-1210-52, DGS-1210-52MP.
![](/pt/pt/-/media/images/es/banners/banner-nuclias-connect-sw-animado.gif?h=356&w=600&la=pt-PT&hash=25ACE642A9384AE267C66C8436E91C40)
Smart Managed with a Plus
With increased PoE output, advanced Layer 2 management features, and Layer 3 static routing , D-Link’s DGS-1210 Smart+ Managed Gigabit Switches provide a cost-efficient and flexible solution for expanding any business network.
Advanced Layer 2 Management with Layer 3 Static Routing
The DGS-1210 Smart+ family has advanced network management options, accessible via Compact CLI or the Web-based UI, that equip your business with network capabilities such as VLANs, multiple spanning tree protocol (MSTP), link aggregation (LACP), static routing, dual software images, and dual configuration files.
With powerful security features like IGMP snooping, access control lists, port security, and the unique D-Link Safeguard Engine that protects your network against malicious denial-of-service attacks from broadcast, multicast and unicast flooding, the DGS-1210 Smart+ family is a versatile solution for access-edge network environments.
![](/pt/pt/-/media/product-pages/dgs/1210-plus/assets/advanced-l2-management-features.png?h=560&w=560&la=pt-PT&hash=858CE537BB882945E5D56F0C814732EA)
Fibre Uplinks
Use fibre uplinks to connect across longer distances, like factory lines and university campuses, using lightweight, secure, and energy-efficient fibre optic cabling that’s immune to interference and which has access to higher throughput to protect the future demands of your business network.
![](/pt/pt/-/media/product-pages/dgs/1210-plus/assets/fibre-uplinks.png?h=570&w=1358&la=pt-PT&hash=7A55A3E0D6C2FFC017BB0FD3F546ED42)
PoE and PoE+, with budgets up to 370W
The DGS-1210 Smart+ Series includes a range of high power budget PoE-enabled switches for businesses looking to power larger deployments of VoIP phones, wireless access points or network cameras.
Gestão Unificada gratuita
Nuclias Connect (DNC-100) é o software gratuito de gestão unificada de Pontos de Acesso Wi-Fi das famílias DAP e Switches Smart Managed da gama DGS-1210*
- Gestão centralizada de Pontos de Acesso e Switches desde a web e/ou app gratuita, sem custos nem licenças.
- Wireless: Análise de tráfego, gestão de RF e canais, portal cativo, SSIDs, etc.
- Switching: Gestão de portas, segmentação com VLANs, listas de controle de acesso, Spanning Tree, etc.
- Instalável em Windows ou Linux. Opção controladora física com custo (DNH-100)
- Fácil descobrimento em layer 2/3 de Pontos Acesso e Switches.
- Aprovisionamento em bloco de múltiplos pontos de acesso com móvel desde a app (iOS/Android)
*Requer instalar a última versão de Nuclias Connect (1.2.0.5). Switches compatíveis (após atualizar o seu firmware)
DGS-1210-10, DGS-1210-10P, DGS-1210MP, DGS-1210-20, DGS-1210-26, DGS-1219-28, DGS-1210P, DGS-1210-28MP, DGS-1210-52, DGS-1210-52MP.
![](/pt/pt/-/media/images/es/banners/banner-nuclias-connect-sw-animado.gif?h=356&w=600&la=pt-PT&hash=25ACE642A9384AE267C66C8436E91C40)
Free Network Design and Management Software
D-Link’s free Network Assistant (DNA) displays all connected devices and speeds up the first time configuration. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools. Optional upgrade licenses allow you to broaden your network and analysis.
![](/pt/pt/-/media/product-pages/dgs/1210-plus/assets/manage.jpg?h=390&w=560&la=pt-PT&hash=8FFB78CA72D180189E0773C4E66B313D)
Smart Energy-Saving Design
D-Link Green technology enables the DGS-1210 Smart+ series to save power without any sacrifices. The majority of the family utilises a fanless design, otherwise they feature a smart fan that powers on above a certain temperature. All come with advanced silicon technology which saves up to 73% of energy compared to a normal switch.
![](/pt/pt/-/media/product-pages/dgs/1210-plus/assets/dlink-green-logo.png?la=pt-PT&h=409&w=370&mw=520&hash=F6B9BC8F7F3CBE07919FDEAE08F605FB)
Surveillance Mode
Select Surveillance Mode in the Web UI to take advantage of easy-to-use surveillance features which enable you to manage your surveillance network effortlessly. It automatically detects your security devices and segments them into a dedicated Auto Surveillance VLAN to handle video surveillance traffic securely and efficiently.
![](/pt/pt/-/media/product-pages/dgs/1210-plus/assets/ip-surveillance-mode.png?h=380&w=1600&la=pt-PT&hash=65319DF899837ABFED71B638E7305EB1)
![](/pt/pt/-/media/product-pages/dgs/1210-plus/assets/dgs1210plus_dlinkassist.png?h=335&w=1600&la=pt-PT&hash=06AF58D96621567358D444F28330948A)
Free Next-Business-Day Service
Enjoy our free Next Business Day service, as standard with D-Link Business products, to replace faulty equipment quickly.
Our rapid-response technical support is designed to ensure businesses get the best support for their unique environment. Our extended warranty and enhanced service packages increases the lengths of warranties and further minimises downtime.
![](/pt/pt/-/media/product-pages/dwl/6620aps/assets/dwl6620aps_14_assistlogo.png?h=92&w=224&la=pt-PT&hash=243EE2B431D9D3BD1DB29923ADB539D5)
We're here to help.
![](/pt/pt/-/media/product-pages/common/callouts/icon_35years.png?h=113&w=142&la=pt-PT&hash=158614DE21FE60989FC06B30678FEDCA)
Over 35 years in the networking industry
Innovative end‑to‑end solution experts for small businesses to large corporations around the world.
![](/pt/pt/-/media/product-pages/common/callouts/icon_support.png?h=113&w=86&la=pt-PT&hash=D63CFD56D582E443B3629991EAE9A64C)
Talking to us is easy
Skilled local support in 16 countries. Our support teams are ready to help you.
![](/pt/pt/-/media/product-pages/common/callouts/icon_limitedlifetime_warranty.png?h=113&w=108&la=pt-PT&hash=86A92B36407B4F3E0E41801503AA3FC6)
D-Link Limited Lifetime warranty
The quality and reliability of D-Link products enable us to provide an industry-leading Limited Lifetime Warranty with every registration.
DGS-1210 Smart+ switch series
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121010f1image-lfront.png?mh=300&h=300&w=796&la=pt-PT&hash=69D428C0EA790F9C2A2718670CF76EE6)
· 8 x 1000Base-T
· 2 x SFP
· Fanless
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121010pf1image-lfront.png?mh=300&h=300&w=796&la=pt-PT&hash=706E2E935D1B5D4D691F9285E6591C1D)
· 8 x 1000Base-T 802.3af/802.3at PoE
· 2 x SFP
· 65W PoE budget
· Fanless
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121010mpf1image-lfront.png?mh=300&h=300&w=823&la=pt-PT&hash=A06337C4CDC64729780F66995642B1DC)
· 8 x 1000Base-T 802.3af/802.3at PoE
· 2 x SFP
· 130W PoE budget
· Fanless
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121020f1image-lfront.png?mh=300&h=300&w=693&la=pt-PT&hash=54859DA83F0E8411F1C750D489D4BFC1)
· 16 x 1000Base-T
· 4 x Combo
· Fanless
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121026f1image-lfront.png?mh=300&h=300&w=1162&la=pt-PT&hash=CCD8E5BDC46AD62CB3DE21CB447510B7)
· 24 x 1000Base-T
· 2 x SFP
· Fanless
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121028f1image-lfront.png?mh=300&h=300&w=1152&la=pt-PT&hash=0D5CA76048AD49AD66BBA475D42CEF90)
· 24 x 1000Base-T
· 4 x Combo
· Fanless
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121028pf1image-lfront.png?mh=300&h=300&w=912&la=pt-PT&hash=3A0842829774F7D2D5417321F3D7FC2B)
· 24 x 1000Base-T 802.3af/802.3at PoE
· 4 x Combo
· 193W PoE budget
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121028mpf1image-lfront.png?mh=300&h=300&w=912&la=pt-PT&hash=B1BD97F9F7EBA7F7345DBE41B09D3998)
· 24 x 1000Base-T 802.3af/802.3at PoE
· 4 x Combo
· 370W PoE budget
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121052f1image-lfront.png?mh=300&h=300&w=978&la=pt-PT&hash=F279D0CA12410FD3F16B709A2AECC091)
· 48 x 1000Base-T
· 4 x Combo
· Fanless
![](/pt/pt/-/media/product-pages/dgs/1210/f1/dgs121052mpf1image-lfront.png?mh=300&h=300&w=711&la=pt-PT&hash=913A000461202958E7B80A035A2DA0B1)
· 48 x 1000Base-T 802.3af/802.3at PoE
· 4 x Combo
· 370W PoE budget
Related Products
![](/pt/pt/-/media/product-pages/dv/700/dv700.png?h=100&w=178&la=pt-PT&hash=49665CAED088C0B82639DB8BA6EC5B06)
![](/pt/pt/-/media/product-pages/dem/310gt/dem-310gt-left.png?h=100&w=178&la=pt-PT&hash=7511F84F6ACCD24D3E325F76EE175373)
![](/pt/pt/-/media/product-pages/dem/311gt/dem311gtg1image-lside.png?h=100&w=178&la=pt-PT&hash=6323D655F78D377BCFEB062C68363FFB)
![](/pt/pt/-/media/product-pages/dem/312gt2/dem-312gt2-left.png?h=100&w=178&la=pt-PT&hash=DA09DC3DC35E6F6E5E29BFB4F30E09BF)
Specs
Type
|
Smart managed |
---|---|
Number of ports
|
16 to 30 ports 48 to 54 ports 5 to 14 ports |
Layer
|
Layer 2 |
Main type of ports
|
1000BASE-T Gigabit Ethernet |
Type of uplink ports
|
Combo 1000BASE-T/SFP SFP |
Switching capacity
|
104 Gbps 20 Gbps 40 Gbps |
PoE options
|
802.3af 802.3at |
Number of PoE ports
|
24 8 |
PoE power budget
|
See datasheet See datasheet |
D-Link Green
|
Supported
|
802.3az Energy-Efficient Ethernet support
|
Supported
|
Form Factor
|
Desktop Rackmountable |
MAC address
|
16K 8K |
Spanning Tree Protocol
|
802.1D STP 802.1s MSTP 802.1w RSTP |
Link aggregation
|
802.3ad |
VLAN group (max static)
|
256 |
Advanced VLAN
|
Asymmetric VLAN Auto Surveillance VLAN Auto Voice VLAN |
Number of QoS queues per port
|
8 |
CoS based on contents
|
Supported
|
Bandwidth control
|
16 Kbps minimum granularity |
ACL type
|
Ingress |
ACL based on packet contents
|
Supported
|
Encryption protocol supported
|
SSL (v1/v2/v3) |
IP-MAC-port binding (IMPB) / Smart Binding
|
Supported
|
ARP spoofing
|
Supported
|
802.1X access control
|
Supported
|
SNMP (v1/v2c/v3)
|
Supported
|
LLDP-MED
|
Supported
|
ICMPv6
|
Supported
|
