EyeOn™ Baby Monitor Junior Plus

DCS-820L

  • Product Status: End of Life

Keep an eye on your little one with the DCS-820L EyeOn™ Baby Monitor Junior Plus. This portable monitor transforms your mobile device into a versatile, yet easy to use baby monitor. Connect to the monitor wirelessly or over the Internet so you can check on your infant no matter where you are. It includes a wide array of features to help you care for your child, including night vision, motion and sound detection. It can even play gentle lullabies to help ease your baby to sleep!

lullabies

5 Classic lullabies

Choose from 5 gentle lullabies to soothe your baby with the built-in speaker.

Peace of Mind, anywhere, anytime

The EyeOn™ Baby Monitor Junior is specially designed to make it easy for you to care for your baby. Its versatile all-day monitoring turns on night vision automatically when it gets dark, giving you a clear picture day or night so you can keep an eye on things anytime. It’s perfect for use in the home, or even when you’re away; it’s mydlink™-enabled, which means that you can check on your baby remotely and securely over the Internet.

nightvision

Day & Night vision

Keep an eye on your little one day or night with up to 16 feet of visibilty in the dark.

Sophisticated technology to keep you informed

The EyeOn™ Baby Monitor Junior can send you notifications you when your baby needs your attention. It can detect movements and sounds, such as baby crying, and alert you immediately. Not only can you see and hear your infant, but you can also comfort them with the sound of your voice through two-way audio2.

snapshots

Photos & Snapshots

Save your photos and video clips directly to your mobile device's photo/video folder for easy sharing.

soundmotion

Sound & Motion detection

Recieve instant notification alerts when a movement of loud noise is detected.

Perfectly Portable for instant monitoring anywhere

You can take the EyeOn™ Baby Monitor Junior with you when travelling with your child, even when there is no available Internet connection. Just connect your mobile device to the EyeOn™ Baby Monitor Junior’ wireless network for instant local monitoring, making it perfect for family holidays or just visiting friends. You can even connect it to an external USB battery1 for total portability!

2wayaudio

Two Way Audio

Whether you'r in the next room or away from home, comfort your baby with the sound of your voice.

Simple to use

Getting started is quick and easy; the free mydlink™ Baby Monitor app for iOS and Android mobile devices not only guides you step by step through the setup process but also gives you an easy to use interface for all the advanced features of the EyeOn™ Baby Monitor Junior. Check on your baby at a glance, pinch to zoom in and out with ease or play one of five gentle lullabies to soothe your child. You can even take snapshots and video clips and save them directly to your mobile device! Just download the free mydlink™ Baby Monitor app for your smartphone or tablet and you can quickly and easily setup and view your EyeOn™ Baby Monitor Junior from anywhere with a wireless or 4G LTE/3G connection. You can also log onto the secure mydlink™ web portal on your computer to keep an eye on what matters most!

zoom

4x Digital zoom

View more details of your baby with a few simple gestures.

app

mydlink™ Baby Camera Monitor

Whether you're at home or on-the-go, the mydlink™ Baby Camera Monitor keeps you connected to your baby and allows you to manage all of your camera's features directly from your mobile device.

connectdirectly

Connect directly

Even when an internet connection isn't available you can connect your mobile device to the camera's wireless network for instant local monitoring.

Monitoring your baby has never been easier!

  • Sound & Motion Detection
  • Plays lullabies
  • 4x Digital zoom
  • microSD Card slot for recording triggered by sound or motion
  • Instant push alerts
  • Remote viewing
  • 2 way audio
  • Take snapshots/ Videos directly to your mobile device

1. USB battery not included, requires at least 2 A output.
2. SD card not included. SDHC Class 6 card or above is recommended. Supports card capacities up to 32GB.

Specs

Indoor/outdoor
Indoor
Connectivity
Wireless
Resolution
VGA 0.3 megapixel
Image sensor
1.5" VGA progressive scan CMOS
Maximum Video Resolution
640 x 480 (other)
Lens
1.1 mm
1.25 mm
1.37 mm
1.5 mm
1.7 mm
1.72 mm
1.8 mm
1.9 mm
1-10.5 mm
180 Degrees Panoramic Wide Eye
2.2 mm
2.38 mm
2.39 mm
2.4 mm
2.44 mm
2.45 mm
2.5 mm
2.55 mm
2.7 mm
2.7~12 mm
2.8 mm
2.8-12 mm
2.97 mm
2.9-8.2 mm
3 mm
3.0 mm
3.15 mm
3.1-8 mm
3.28 mm
3.3 mm
3.3-12 mm
3.4-122.4 mm
3.45 mm
3.4-61.2 mm
3.5-8 mm
3.6 mm
3.8-45.6 mm
3-9 mm
4 mm
4.12 mm
4.3 mm
4.37 mm
4.7-96 mm
4_5_10 mm
5.01 mm
6 mm
CS Mount
DC iris varifocal
F1.0
F1.2
F1.2-2.3
F1.4
F1.4-2.9
F1.4-3.0
F1.4-360
F1.5
F1.6
F1.6~2.9
F1.6-2.7
F1.8
F1.85
F1.9
F2.0
F2.1
F2.2
F2.4
F2.5
F2.8
Fisheye
Fixed
Motorised P-iris
Motorised Varifocal
Varifocal
Infrared-Cut Removable Filter
Supported
Night vision
Supported
Night vision range
5 m
2-way audio
Supported
Built-in Microphone
Supported
Built-in Speaker
Supported
External Card Slot
MicroSD SDHC (max 32 GB)
App Support
mydlink EyeOn Baby
Video Format
H.264
Digital Zoom
4x
Motion Detection
Supported
Sound Detection
Supported
Event Recording
Supported
Plays lullabies
Supported
This product was phased out on: 15/03/2017
This product's last date of support is on: 15/03/2019
How to install and use the Mydlink Lite app on your iPhone/iPad
How to remove a camera from your Mydlink account
How to Log into a Mydlink camera
Version Date Type File Size
Datasheet - - - Download
Version Description Date Type File Size
1.10 Quick installation guide 19/11/2014 - - Download
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:

http://tsd.dlink.com.tw/GPL.asp

The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
Version Description Date Type
1.04.03 Firmware 02/03/2016 - Download
Firmware Release notes included 1.03.05 Firmware
Release notes included
03/07/2015 - Download
Version Description Date
Lullaby Upload Utility and How-To Guide Lullaby Upload Utility and How-To Guide - Download
Version Description Date
CE declaration CE declaration 16/10/2014 Download
