Full HD PoE Day/Night Network Camera

DCS-2210L

  • Product Status (Revision A): End of Life

Full HD PoE Day/Night
Network Camera


The D-Link DCS-2210L Full HD PoE Day/Night Network Camera is a versatile camera perfect for monitoring low-light environments in your home or small office. It combines a high-resolution 2-megapixel sensor with a built-in IR LED to help you keep watch over areas in complete darkness.

Monitoring Your Home Has Never Been Easier!

  • HD 1080p High Quality Video

  • Push Alert Notifications

  • Two-Way Audio

  • PoE

  • Day & Night

  • Snapshots

  • microSD/SDHC Card Slot1 - Record snapshots and videos triggered by motion or sound

Easy Do-it-Yourself Setup

  • Step1: Install

  • Step 2: Place

  • Step 3: Monitor

Download the free mydlink® app for your iPhone, iPad or Android device and follow the simple
steps to set up your camera.

mydlink® App


Whether you're at home or on-the-go, the mydlink® app keeps you connected and allows you to manage all of your camera's features directly from your mobile device.

Full HD 1080p High
Quality Video


Never miss a detail with the sharp clarity of 1080p Full HD picture for the best monitoring experience.

Survey a large area easily


Get a closer look with ePTZ, which lets you zoom in, zoom out,
and pan across your camera’s video so you can survey a large area easily.

PIR Motion
Detection


Receive alert notifications when  movement is detected.

Day & Night Vision


Keep an eye on your home day or night with up to 5 metres of visibility in the dark.

Photo Snapshots


Save your photos  directly to your mobile device's photo folder for easy sharing.

PoE


The DCS‑2210L includes support for Power over Ethernet (PoE), so the camera can be placed in areas where no power outlet is nearby2.

D-ViewCam3


If you want to expand your surveillance options, D-ViewCam™ management software is also included, giving you the ability to manage up to 32 cameras with a robust set of features, including multi-camera views and automated e-mail alerts to keep you informed of suspicious or unusual activities.
1 MicroSD card not included
2 PoE switch required
3 D-ViewCam software included is not Mac-compatible.

Specs

Download the datasheet.

Indoor/outdoor
Indoor
Resolution
Full HD 2 megapixel
Image sensor
1/2.7" 2 megapixel progressive scan CMOS
Maximum Video Resolution
1920 x 1080 (16:9)
1440 x 1080 (other)
Lens
Fixed
2.8 mm
F1.8
Infrared-Cut Removable Filter
Supported
Night vision
Supported
Night vision range
5 m
PIR(Passive Infrared)sensor
Supported
Privacy Masks
3 zones
2-way audio
Supported
Built-in Microphone
Supported
Built-in Speaker
Supported
Connectivity
Wired PoE
Digital Input/Output(DI/DO)
1/1
External Card Slot
MicroSD SDHC (max 32 GB)
App Support
mydlink
Video Format
H.264
MJPEG
MPEG-4
Multi-Stream
Supported
Mobile Stream
Supported
Features
ONVIF
Digital Zoom
10x
Motion Detection
Supported
Event Recording
Supported
E-mail Notification
Supported
Recording to NAS
Supported

O desempenho real pode variar devido a configurações, cablagem, temperatura, configuração de rede, interface, compatibilidade de dispositivos, condições ambientais e locais e outros fatores semelhantes. As referências à capacidade de energia, velocidade de sinal ou processamento, alcance ou distância do sinal, encriptação de dados, capacidade de armazenamento, propriedades de exibição ou outras métricas de desempenho são baseadas em condições ideais derivadas de padrões da indústria e fornecidas apenas para fins informativos. As especificações estão sujeitas a alterações sem aviso prévio.

Download the datasheet.

Support

This product was phased out on: 22/04/2018
This product's last date of support is on: 21/04/2020
Version Date Type File Size
Datasheet - PDF 0.34mb Download
Version Description Date Type File Size
Product manual Product manual 27/11/2015 PDF 3.99mb Download
Version Description Date Type File Size
Quick installation guide Quick installation guide 27/11/2015 PDF 1.75mb Download
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:

http://tsd.dlink.com.tw/GPL.asp

The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
Version Description Date Type
1.02.00

Release notes included

 27/01/2016 - Download
1.01.00 Firmware 19/10/2015 - Download
Version Description Date
Setup Wizard Find the latest Setup Wizard on our Mydlink site.
Make sure to select the correct model and version.		 13/01/2016 Download
Version Description Date
DNR_2020_04P_Cam_Support_list DNR-2020-04P Camera Support List 22/09/2016 Download
CE doc 1.20 Revision A1 CE document 01/06/2016 Download
