Specifiche tecniche
Device Ports
PPP over Ethernet Client PPPoE (RFC 2516)
Internet Support
Audio Code
G.168
Telephone Function Support
Transparent fax (G.711)
Others
Signaling, RTP packets)
IP Packet Routing
IPSec and PPTP pass-through
IP Multicast
DSP/Ethernet statistics
Firmware Upgrade, Configuration Backup/Restore
TFTP support
Built-in Router
Configuration & Management
IP Number Assignment
DHCP server
Self Identification
Power
- 2 FXS RJ-11 ports
- 10/100BASE-TX RJ-45 port for DSL/cable modem connection
- 4 10/100BASE-TX RJ-45 ports for LAN connection
- RJ-14 port console port
PPP over Ethernet Client PPPoE (RFC 2516)
Internet Support
- IP, TCP, UDP, ARP protocols
- HTTP 1.1
- DHCP client
- DNS
- MGCP *
- SIP
Audio Code
- G.711u-law/A-law
- G.723.1
- G.726
- G.729A
G.168
Telephone Function Support
- DTMF dial tone signal support
- Dial pulse support
- Caller ID support
Transparent fax (G.711)
Others
- Call waiting alert tone support
- Play ring splash to phone when system ready with registered
- QoS
Signaling, RTP packets)
IP Packet Routing
- DHCP/NAT
- IP filtering
- TCP/IP with RIP v.1, RIP v.2 (RFC 1389), Static Routing
- ICMP (RFC 791)
- UDP (RFC 792)
- ARP (RFC 826)
IPSec and PPTP pass-through
IP Multicast
- IGMP Proxy
- Multicast forwarding
- Dynamic Host Configuration Protocol (DHCP) server/client
- (RFC 2131)
- Network Address Translation (NAT)
- Telnet
- Web-based
- Out-of-band through console port
- PPP Authentication Protocol (RFC 1334)
- Challenge Handshake Authentication Protocol with PPP (RFC 1994)
DSP/Ethernet statistics
Firmware Upgrade, Configuration Backup/Restore
TFTP support
Built-in Router
Configuration & Management
IP Number Assignment
DHCP server
Self Identification
- DHCP client
- Bootp
Power
- Status
- ADSL Link/Act
- LAN 10 or 100Mbps Speed (per LAN port)
- Phone On/Off/Ringing (per FSX port)
- 12VDC 1.25A, through external power adapter
- 10 watts (max.)
- 193 (L) x 118 (W) x 30 (H) mm (device only)
- 0o to 40 oC
- 10o to 55 oC
- 5% to 95% non-condensing
- FCC Class B
- CE
- CB (IEC60950)
Supporto
This product was phased out on: 13/01/2010
Data più recente dell'intervento di assistenza: 13/01/2012
Versione | Data | Tipo | Dimensioni file | |
---|---|---|---|---|
Datasheet (English) | - | 0.25mb | Download |
Versione | Descrizione | Data | Tipo | Dimensioni file | |
---|---|---|---|---|---|
Manual (English) | Manual (English) | - | 2.97mb | Download |
Versione | Descrizione | Data | Tipo | Dimensioni file | |
---|---|---|---|---|---|
Quick Installation Guide (English) | - | 0.32mb | Download |
Versione | Descrizione | Data | Tipo | |
---|---|---|---|---|
Firmware DVG-1402S 1 Correct the 1.00.009 | Firmware DVG-1402S |
31/08/2006 | - | Download |
