Media Converter 1 porta RJ45 1000BASE-T / 1 porta fibra ottica 1000BASE-SX (SC)
DMC-700SC
- Stato del prodotto: End of Life
Description
The DMC-700SC by D-Link® is a media converter designed to connect 1000BASE-SX fiber to 1000Base-T copper media or vice versa. Based on the IEEE 802.3ab and 802.3z standards, the DMC-700SC is designed for use with multi-mode fiber cable utilising the SC-Type connector. The DMC-700SC supports shortwave (SX) laser specifications at a full wire-speed forwarding rate. Other features of this module include the ability to be used as a standalone device (no chassis required), Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The DMC-700SC will transmit at extended fiber optic distances utilising multimode fiber up to 550 meters.
The DMC-700SC by D-Link® is a media converter designed to connect 1000BASE-SX fiber to 1000Base-T copper media or vice versa. Based on the IEEE 802.3ab and 802.3z standards, the DMC-700SC is designed for use with multi-mode fiber cable utilising the SC-Type connector. The DMC-700SC supports shortwave (SX) laser specifications at a full wire-speed forwarding rate. Other features of this module include the ability to be used as a standalone device (no chassis required), Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The DMC-700SC will transmit at extended fiber optic distances utilising multimode fiber up to 550 meters.
Specifiche tecniche
Specifiche tecniche
Indicatori LED
Certificazioni
L'aspetto del prodotto reale può differire dall'immagine visualizzata in questa pagina.
Indicatori LED
- PWR (alimentazione)
- LINK/ACT
- 120 x 88 x 25 mm
- 7.5V 1.5A
- Alimentatore esterno
- 0° ~ 40°C
- -25° ~ 70°C
- 10 ~ 90% (non-condensata)
Certificazioni
- FCC Class B
- VCCI Class B
- CE Class B
- C-Tick
- 2 anni
L'aspetto del prodotto reale può differire dall'immagine visualizzata in questa pagina.
Supporto
This product was phased out on: 28/09/2023
Data più recente dell'intervento di assistenza: 13/05/2024
