Specs
System Requirements
- Laptop with available CardBus Type II slot
- Windows XP, 2000, ME or 98 SE
- 300MHz CPU or above
- 32MB memory or more
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11g
- PC Card Standard & Interface
- PC Card Type II CardBus 32-bit compliant
- CSMA/CA with ACK
- (With automatic fallback)
- 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps,
- 9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps
- Orthogonal Frequency Division Multiplexing (OFDM)
- Complementary Code Keying (CCK)
- Direct Sequence Spread Spectrum (DSSS)
- 2.4GHz to 2.4835GHz
- 5.15GHz to 5.250GHz
- Software configurable as allowable frequency will vary from country to country in the European region
- 802.11a:
- 10 to 14dBm @ 54Mbps
- 11 to 15dBm @t 48Mbps
- 13 to 15dBm @t 36Mbps
- 17 to 18dBm @ 24, 18, 12, 9 and 6Mbps
- 802.11b:
- 18dBm @ 11, 5.5, 2, and 1Mbps
- 802.11g:
- 10 to 14dBm @ 54Mbps
- 11 to 15dBm @ 48Mbps
- 13 to 15dBm @ 36Mbps
- 17 to 18dBm @ 24, 18, 12, 9 and 6Mbps
- 802.11a (@ 10% PER):
- 87dBm for 6Mbps
- 86dBm for 9Mbps
- 85dBm for 12Mbps
- 83dBm for 18Mbps
- 80dBm for 24Mbps
- 76dBm for 36Mbps
- 71dBm for 48Mbps
- 66dBm for 54Mbps
- 802.11b (@ 8% PER):
- 84dBm for 11Mbps
- 90dBm for 2Mbps
- 802.11g (@ 10% PER):
- 87dBm for 6Mbps
- 86dBm for 9Mbps
- 85dBm for 12Mbps
- 83dBm for 18Mbps
- 80dBm for 24Mbps
- 76dBm for 36Mbps
- 71dBm for 48Mbps
- 66dBm for 54Mbps
- 2dBi to 4dBi Gain integrated antenna
- Indoors: up to 100 meters *
- Outdoors: up to 400 meters *
- Environmental factors may adversely affect range.
- 64/128/152-bit WEP data encryption
- 802.1x authentication
- WPA (Wi-FiTM Protected Access): 802.1x, Pre Share Key, WEP, TKIP, AES
- Power
- Network
- 5 VDC +/- 10%
- Transmit mode: 1947mW
- Receive mode: 1056mW
- Sleep mode: 40mW
- 118 (L) x 53 (W) x 5 (H) mm (including antenna)
- 84 (L) x 53 (W) x 3 (H) mm (adapter only)
- 41grams (adapter including antenna)
- 0o to 45 oC
- 10o to 60 oC
- 95% maximum (non-condensing)
- FCC Class B
- CE Class B
- Windows 98 SE, ME, 2000, XP
Support
This product was phased out on: 17/05/2011
Última fecha de asistencia 16/05/2013
No hay descargas
