54Mbps PCMCIA CardBus 802.11a/b/g Wireless Adapter

DWL-AG650

  • състоянието на продукта (Revision A): End of Life

Технически характеристики

Свалете таблицата с характеристики.


Physical & Environmental
  •  Laptop/notebook PC with 32-bit CardBus slot
  •  500MHZ processor or above
  •  128MB memory or more
  •  CardBus controller properly installed and working in Win98 SE, ME, 2000, XP computer
Standards
  •  IEEE 802.11a
  •  IEEE 802.11b
  •  IEEE 802.11g
Bus Type
  • 32-bit CardBus
Media Access Control
  • CSMA/CA with ACK
Data Rates
  • (With automatic fallback)
  • 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps,
  • 6Mbps, 5.5Mbps, 2Mbps, 1Mbps
Modulation Technology
  •  Orthogonal Frequency Division Multiplexing (OFDM)
  •  Complementary Code Keying (CCK)
  •  Direct Sequence Spread Spectrum (DSSS)
Transmit Output Power
  • 15 dBm +/- 2dBm
Receiver Sensitivity
  • 54Mbps OFDM, 10% PER, -73dBm
  •  48Mbps OFDM, 10% PER, -76dBm
  •  36Mbps OFDM, 10% PER, -82dBm
  •  24Mbps OFDM, 10% PER, -85dBm
  •  18Mbps OFDM, 10% PER, -88dBm
  •  12Mbps OFDM, 10% PER, -89dBm
  •  11Mbps CCK, 8% PER, -91dBm
  •  9Mbps OFDM, 10% PER, -90dBm
  •  6Mbps OFDM, 10% PER, -91dBm
  •  5.5Mbps CCK, 8% PER, -92dBm
  •  2Mbps QPSK, 8% PER, -93dBm
  •  1Mbps BPSK, 8% PER, -94dBm
Antennas
  • Diversity switching dual internal antennas
Operation Range
  •  Indoors: up to 100 meters (328 feet)*
  •  Outdoors: up to 400 meters (1,312 feet)*
  •  Environmental factors may adversely affect range
Security
  •  64/128-WEP data encryption
  •  802.1x authentication
  •  WPA (Wi-Fi Protected Access): 802.1x, Pre Share Key, WEP, TKIP, AES*
  •  AES support in software will be released in future upgrade
Diagnostic LEDs
  •  Link
  •  Activity
Power Consumption
  •  Power save mode: 70mW
  •  Transmit mode: 1650mW
  •  Standby mode: 1250mW
Dimensions
  • 114.3 (L) x 54 (W) x 8.7 (H) mm (4.64 x 2.13 x 0.34 inches)
Weight
  • 55 grams (0.12 lb.)
Operating Temperature
  • 0o to 55 oC
Storage Temperature
  • 10 o to 60 oC
Humidity
  • 95% maximum (non-condensing)
EMI Certification
  •  FCC Class B
  •  CE Class B
  •  C-Tick
O.S. Support
  • Windows 98 SE, ME, 2000, XP

Product Support Section

Този продукт ще бъде прекратен на: 16/01/2006
Последната дата на поддръжка на този продукт е: 16/01/2008
Версия Дата Тип Размер на файла
Datasheet (English) - PDF 0.40mb Свали
Версия Описание Дата Тип Размер на файла
Manual (English) Manual (English) 27.3.2003 г. PDF 2.40mb Свали
Версия Описание Дата Тип Размер на файла
Quick installation guide (English) - PDF 2.17mb Свали
Версия Описание Дата
DEU_Drivers_v2_41_32_RevA Drivers v2.41.32 24.8.2003 г. Свали
Версия Описание Дата
DEU_CE_B2_RevA Certificate of Declaration B2 20.2.2004 г. Свали
DEU_CE_RevA Certificate of Declaration 25.7.2003 г. Свали
