8-Port Gigabit Unmanaged Industrial Switch
DIS-100G-8W
- Statut produit (Revision A1_v200): Live
- 8 x 10/100/1000BASE-T ports
- -40°C to +75°C wide operating temperature range
- IP30-rated solid metal housing
- High EMC endurance
- Dual power input for redundant power supplies
- DIN-rail and wall-mounting options
- Compliant with EN-50121-4 wayside control and NEMA-TS2 traffic control standards
Voir la liste de nos partenaires
Durable, Reliable, and Efficient
The DIS-100G Series switches are housed in a highly resistant IP30-rated metal casing to protect the switches from harsh environmental conditions. The high electromagnetic compatibility (EMC) protects the DIS-100G Series from unwanted effects when operating in environments with strong electromagnetic interference.
Fully Compliant
The D-Link DIS-100G Series industrial switches are compliant with all international requirements for product safety and electromagnetic compatibility that ensure safe deployment. Moreover, the DIS-100G Series fully complies with the EN50121-4 wayside control and NEMA-TS2 traffic control standards, which makes these switches an ideal solution for Intelligent Transportation System (ITS) applications.
Specification
|
Interfaces
|
8 x 10/100/1000 BASE-T ports 8 x 1000Base-T ports Auto MDI/MDIX |
|---|---|
|
Alarm Port
|
Yes |
|
Switching Capacity
|
16 Gbps |
|
Maximum Forwarding Rate
|
11.9Mpps |
|
Dimensions
|
117.8 x 39 x 96.9 mm |
|
Weight
|
0.443kg |
|
Temperature
|
Operating -40 ~ 75℃ Storage -40 ~ 85℃ |
|
Humidity
|
Operating: 5% to 95% RH, non-condensing Storage: 5% ~ 95% RH |
|
Maximum Heat Dissipation
|
26.61 BTU/hr |
|
Operating Altitude
|
2000 m |
|
Max Power Consumption
|
7.8W |
|
MTBF
|
> 25 years |
|
Power Input
|
12-58Vdc |
|
FAN
|
Fanless |
|
Actual performances may vary due to settings, cabling, temperature, network configuration, interface, device compatibility, environmental and on-site conditions, and other similar factors. References to power capability, signal or processing speed, signal range or distance, data encryption, storage capacity, display properties, or other performance metrics are based on optimal conditions derived from industry standards and provided for informational purposes only. Specifications may be subject to change without prior notice. |
|
