Sharecenter™ 2-Bay Network Storage Enclosure

DNS-325, DNS-325-1TB, DNS-325-2TB

  • Product Status (Hardware Version: Ax): End of Life
RAID 1 Technology
RAID 1 is like a backup for your backup. It causes the drives in your storage device to mirror each other, so if one drive fails the unaffected drive will continue to function until the failed one is replaced.

Web File Server and FTP Server
The DNS-325 includes a built-in Web File server and FTP server to make accessing files remotely, over the Internet, a breeze. The FTP server will come in handy when you need to share a file too big to e-mail to a friend.

DLNA Server
This ShareCenter device has a built-in media server that can stream your photos, music and videos to all of the computers in your home and to compatible media players like Boxee Box, Xbox and PlayStation 3 so you can enjoy it all on your TV.

10/100/1000 Gigabit Port
The 10/100/1000 Gigabit Ethernet port gives you blazing fast speeds so you can back up and access your data without the wait.

Cooling Fan
There’s no overheating in this device’s future. It comes with a quiet, built-in cooling fan that only comes on when needed, saving you power and money.

D-Link Easy Search Utility
The D-Link Easy Search Utility allows you to locate your ShareCenter from anywhere on the network and map your network drive so it will conveniently appear in "My Computer" on your PC.

Backup Software
The included feature-rich backup software allows you to create schedules and rules including full or incremental backups.

Easy Setup
Not quite the handyman? That’s ok. You can insert an additional hard drive without using any tools or attaching any cables. You can insert up to 2 SATA hard drives without using any tools or attaching any cables.

D-Link Green
This product allows hard drives to enter sleep mode when not in use to conserve electricity and prolong the life of the hard disk. Plus, it uses recyclable packaging and complies with the European Union’s RoHS directive.

USB Print Server Port
This storage device can also serve as a USB print server, allowing you to share a single USB printer over your network. The USB port can also support a Universal Power Supply (UPS) monitor that supports ‘smart’ signaling over a USB connection. If a power outage were to occur, the compatible UPS monitor would allow the UPS unit to safely shut down the ShareCenter.

AjaXplorer
AjaXplorer is a file explorer that allows you to remotely manage your files using a web browser. Stay protected - anywhere, anytime.

Mac Friendly
Not to worry, Mac users! ShareCenter can back up your data regardless of your computer's operating system (Windows, Mac or Linux)

Support for:
  • AFP (Mac)
  • Time Machine (Mac)
  • NFS (Linux)

Photo Center
Are you tired of sending individual photos through email? The ShareCenter Photo Center app provides a convenient interface from which you can create and share photo albums with friends and family easily over the web.

Audio Streamer
Stream music throughout your home. The Audio Streamer allows you to transmit multiple streams of audio to any device with an Internet connection, whether it be your computer, TV or tablet.

Logitech Squeeze Center
Connect your Logitech Media Squeezebox player to your ShareCenter and play endless hours of music files stored on your deivce.

Blog

Create and host your own customized Blog from your ShareCenter device. Access and comment on it from anywhere you have an Internet connection.

1Hard drives only included for DNS-325-1TB and DNS-325-2TB. RAID 1 mirroring requires the use of two internal SATA drives. To avoid data incompatibility in RAID 1 operation, use SATA drives from the same manufacturer. Formatted drive capacity for RAID 1 operation is dependant on the drive capacity of the lowest-sized drive. May not work with older generation SATA drives. For a list of SATA drives that have been tested to work with the ShareCenter Shadow, visit D-Link support websites.

Het uitzicht van het product kan afwijken van de afbeelding op deze pagina

Type
Network Attached Storage
Enclosure form factor
Desktop
CPU
Marvell 88F6281 1.2 GHz
FLASH
128 MB
SDRAM
256 MB
Number of drive bays
2
Integrated hard disk drives
1 TB (1 x 1TB)
2 TB (1 x 2TB)
Drive interface
SATA I/II
Drive form factor
3.5 inch
Maximum storage capacity
8 TB
Network interface
1 x Gigabit Ethernet
Number of USB ports (for storage backup, printer sharing or UPS monitoring)
1
D-Link Green with power saving mode and smart fan
Supported
Multiple drive configuration
JBOD
RAID 0/1
standard
RAID migration non-RAID to RAID 1
Supported
Drive format
EXT3
Scan disk
Supported
SMART
Supported
Disk/RAID roaming
Supported
User account management
Supported
Maximum number of user accounts
256
Group account management
Supported
Maximum number of group accounts
32
User/group quota management
Supported
Network share management
Supported
Maximum number of managed shared forlders
128
ISO mount management
Supported
Maximum concurrent connections via FTP
10
Maximum concurrent connections via Samba
64
Schedule backup from PC to NAS
Supported
Schedule local backups
Supported
Schedule remote backups
Supported
Apple Time Machine support
Supported
Cloud storage backup
Amazon S3
USB backup
Supported
mydlink (access and sync, mobile app support)
Supported
FTP/HTTP/P2P downloads
Supported
File sharing protocol
CIFS/NFS/Web File Manager/AFP/WebDAV
Network streaming service
DLNA
iTunes Server
UPnP AV
Add-on support
Supported
Photo Center
Supported
Surveillance Center
Supported
Web interface through browser
Supported
E-mail/SMS notification
Supported
System/FTP log
Supported
This product was phased out on: 26/01/2015
De laatste dag dat ondersteuning beschikbaar is voor dit product is op: 25/01/2017
Getting started with DNS-325
Versie Datum Type Bestandsgrootte
Datasheet (English) - PDF 2.04mb Download
Storage Product Guide - PDF 2.63mb Download
IP Surveillance Guide - PDF 3.58mb Download
Versie Beschrijving Datum Type Bestandsgrootte
Product manual Product manual - PDF 8.92mb Download
Versie Beschrijving Datum Type Bestandsgrootte
- - PDF 0.88mb Download
Dit D-Link product bevat software code welke ontwikkeld is door derden, waaronder software code die valt onder de GNU General Public License ("GPL") of GNU Lesser General Public License ("LGPL"). Indien van toepassing: de voorwaarden van de GPL en LGPL en informatie over het verkrijgen van toegang tot de GPL-code en LGPL-code die in dit product zijn gebruikt, zijn hier voor u beschikbaar:

http://tsd.dlink.com.tw/GPL.asp

De GPL-code en LGPL-code die gebruikt is in dit product wordt gedistribueerd ZONDER ENIGE GARANTIE en is onderworpen aan de auteursrechten van een of meer auteurs. Voor meer informatie, zie de GPL-code en de LGPL-code voor dit product en de voorwaarden van de GPL en LGPL.
Versie Beschrijving Datum Type
Firmware: v1.05 build 04 1.05b04 Firmware: v1.05 build 04 18-11-2016 - Download
Firmware: v1.03 build 03 1.03 b03 Firmware: v1.03 build 03 - - Download
Versie Beschrijving Datum
My Surveillance addon My Surveillance addon 14-3-2016 Download
Software: MyDlink Cloud Package v2.38 2.38

Software: MyDlink Cloud Package v2.38

28-7-2014 Download
Software: Yahoo Widget 2.01 2.01 Software: Yahoo Widget 2.01 1-10-2012 Download
Software: Audio streamer Package 2.01 2.01 Software: Audio streamer Package 2.01 30-8-2012 Download
Software: GPL Code v1.00 1.00 Software: GPL Code v1.00 30-8-2012 Download
Software: Amule Package 2.01 2.01 Software: Amule Package 2.01 3-8-2012 Download
Software: Setup Wizard v1.0.4.3 1.043 Software: Setup Wizard v1.0.4.3 10-1-2012 Download
Software: Storage Utility v5 5.000 Software: Storage Utility v5 6-4-2011 Download
Software: Ajaxplorer 2.01 2.01 Software: Ajaxplorer 2.01 - Download
Software: Blog Package 2.01 2.01 Software: Blog Package 2.01 - Download
Software: Photocenter Package v2.01 2.01 Software: Photocenter Package v2.01 - Download
Software: PnP X-Treiber v1.00 1.00 Software: PnP X-Treiber v1.00 - Download
Software: Squeeze Center Package v2.02 2.02 Software: Squeeze Center Package v2.02 - Download
Versie Beschrijving Datum
Hard disk drive compatibility list

Hard disk drive compatibility list

23-11-2015 Download
Certificate of Declaration rev. A2 Certificate of Declaration rev. A2 20-8-2012 Download
Certificate of Declaration rev. A1 Certificate of Declaration rev. A1 15-12-2010 Download
