8-Port Fast Ethernet Unmanaged Desktop Switch
DES-108
- Product Status (Revision C): Live
The DES-108 8-Port Fast Ethernet Unmanaged Desktop Switch is a 8-port 10/100 Mbps Fast Ethernet switch that allows you to quickly set up a wired network. Connect the DES-108 to multiple computers together to share files and folders, or connect it to a router to share an Internet connection.
Alle Verkooppunten
The DES-108 8-Port Fast Ethernet Unmanaged Desktop Switch is a 8-port 10/100 Mbps Fast Ethernet switch that allows you to quickly set up a wired network. Connect the DES-108 to multiple computers together to share files and folders, or connect it to a router to share an Internet connection.
Auto-Sensing 10/100 Ports
The DES-108 uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.
Auto MDI/MDIX Crossover
All of the ports on the DES-108 support automatic MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables. In addition, the DES-108 features multiple front, easy-to-access Ethernet ports with two colour LED indicators per port to easily distinguish link status.
Flow Control for Secure Transmission
When a port reaches its receiving buffer capacity, the 802.3x flow control feature activates to minimize dropped packets. By minimizing the number of dropped packets, the switch provides a more reliable connection for all of your connected devices while surfing the web, playing games, or accessing media.
Think Green
The DES-108 is a plug-and-play networking switch that offers D-Link’s Green Technology to save energy and reduce heat, which in turn extends product life without sacrificing performance or functionality. The switch supports IEEE 802.3az Energy-Efficient Ethernet (EEE) which detects when a connected computer is shut down or when there is no Ethernet traffic, in which the switch will proceed to power down the idle port, saving a substantial amount of power.
Gerelateerde Producten
![](/nl/nl/-/media/product-pages/des/105/des-105-c2-front.png?h=100&w=178&la=nl-NL&hash=74E5D545651F87D43A7084DCF7F40FF5)
![](/nl/nl/-/media/product-pages/dub/e100/dube100d1image-lside.png?h=100&w=178&la=nl-NL&hash=9EF29F94B973D3BC04DDBF523AEF23FB)
![](/nl/nl/-/media/product-pages/dub/1312/dub1312a1imagelfront.png?h=100&w=178&la=nl-NL&hash=7D95BF6DE4497BA4FDF2BDA0C3433936)
![](/nl/nl/-/media/product-pages/dub/e130/dub_e130_a1_image_side.png?h=100&w=211&la=nl-NL&hash=D0C2BB6744F4FCA1692030BB2A155E1E)
Specs
Type
|
Unmanaged |
---|---|
Number of ports
|
5 to 14 ports |
Main type of ports
|
100BASE-TX Fast Ethernet |
Switching capacity
|
1.6 Gbps |
Fanless
|
Supported
|
D-Link Green
|
Supported
|
802.3az Energy-Efficient Ethernet support
|
Supported
|
Form Factor
|
Desktop |
Housing
|
Metal |
Jumbo frame
|
Supported
|
MAC address
|
1K |
Number of QoS queues per port
|
2 |
Downloads can vary across product revisions. Please select the correct hardware revision.
