Wi-Fi Pan & Tilt Day/Night Camera

DCS-5009L

  • Product Status: End of Life

Monitor your home...

The DCS-5009L Wi-Fi Pan & Tilt Day/Night Camera provides a range of features to help you effectively monitor large areas of your home or small office at all hours of the day. The pan/tilt function allows the camera to patrol a wide area, while the built-in IR LEDs provide around the clock surveillance regardless of the lighting conditions.
Wireless connectivity means there is no need for additional cabling, allowing for flexible placement and hassle-free installation.

Features

Pan & Tilt
Motion Detection
with Instant Alerts
Day & Night Viewing
Wireless N Connectivity
Remote Viewing with mydlink™ Apps
Simple Setup

Sharp Image Monitoring from Different Angles

By providing you with sharp, responsive pan/tilt movement and digital zoom, the Wi-Fi Pan & Tilt Day/Night Camera gives you full control over your surveillance. You can quickly scan a wide area from a variety of angles, and 4x digital zoom lets you zoom in on specific areas for more detail. The DCS-5009L can also be set to move to specific preset positions, allowing the camera to focus on particular areas of interest within the surveillance area.

Peace of Mind with 24/7 Monitoring

The DCS-5009L is a standalone surveillance camera that requires no special hardware or software and can run independently even without a PC. Send e-mail notifications with snapshots or video clips whenever motion is detected using just the DCS-5009L and an Internet connection. You can customise areas of the video image to monitor for motion, allowing you to effectively monitor areas such as entryways or restricted-traffic areas. Night time monitoring is also possible thanks to built-in infrared LEDs which allow for viewing of up to 8 metres (26 feet) in complete darkness, enabling round-the-clock monitoring of your home or small office.

Wired and Wireless Connectivity

Place the DCS-5009L anywhere in your home or small office with the flexibility of either wired or wireless connectivity. Install the DCS-5009L anywhere within range of your existing wireless network, without the need for additional network cabling. Wireless connectivity gives you the flexibility to move the camera from place to place should your surveillance requirements change.

Easy Installation and Flexible Placement

Setting up your Pan & Tilt Wi-Fi Camera is easier than ever with our app-enabled installation wizard. And with the included mounting base, you can place your camera virtually anywhere, connect and view instantly!

mydlink™: the easiest way to setup up your camera and monitor your home

Connecting a camera on your network and accessing it has traditionally required complex configuration. mydlink™ makes it easy to access your camera from wherever you are, whenever it’s convenient for you. Using the free mydlink™ Lite app for iOS and Android smartphones and tablets, you can connect and setup your mydlink™ camera without turning on a computer. A step-by-step guide has your camera up and running in a matter of minutes. Through the mydlink™ Lite app, you can set up a free mydlink™ account which allows you to view and manage your camera from any Internet connected computer. If you have more than one camera, you can add it to your existing mydlink™ account and watch all your cameras from a single location.

Accessing your cameras on the go is easy too. Just download the free mydlink™ Lite app for your iPhone or Android device and you can quickly and easily view your camera feed from anywhere with a wireless or 3G/4G LTE connection. Thanks to this app, you can monitor on-the-go even if you don’t have access to a computer. If you have a mydlink™-enabled Cloud Router, setting up and configuring your DCS-5009L is a snap, thanks to Zero Configuration. Simply connect your camera to its power adapter and then connect your camera to your Cloud Router with an Ethernet cable - the camera will automatically be added to your account.

Specs

Indoor/outdoor
Indoor
Connectivity
Wireless
Resolution
VGA 0.3 megapixel
Image sensor
1.5" VGA progressive scan CMOS
Maximum Video Resolution
640 x 480 (other)
Lens
2.2 mm
F2.0
Infrared-Cut Removable Filter
Supported
Night vision
Supported
Night vision range
8 m
Motorised Pan/Tilt
Supported
Built-in Microphone
Supported
App Support
mydlink
Video Format
H.264
MPEG-4
Multi-Stream
Supported
Mobile Stream
Supported
Motion Detection
Supported
E-mail Notification
Supported
This product was phased out on: 08/03/2017
This product's last date of support is on: 08/03/2019
How to install and use the Mydlink Lite app on your iPhone/iPad
How to remove a camera from your Mydlink account
How to Log into a Mydlink camera
How to Setup and Install a Mydlink camera
How to configure time on a Mydlink camera
How to configure Motion Detection on a Mydlink camera
Version Date Type File Size
Datasheet - - - Download
Version Description Date Type File Size
Product manual

Product manual

16.10.2014 - - Download
Version Description Date Type File Size
1.10

Quick installation guide

16.10.2014 - - Download
This D-Link product includes software code developed by third parties, including software code subject to the GNU General Public License (“GPL”) or GNU Lesser General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL, and information on obtaining access to the GPL code and LGPL code used in this product, are available to you at:

http://tsd.dlink.com.tw/GPL.asp

The GPL code and LGPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors. For details, see the GPL code and the LGPL code for this product and the terms of the GPL and LGPL.
Version Description Date Type
1.08.11 Firmware 06.4.2017 - Download
1.06.02 Firmware 19.10.2015 - Download
1.05.01 Firmware 19.10.2015 - Download
Firmware Release notes included 1.03.1 Firmware
Release notes included
15.5.2015 - Download
Version Description Date
Setup Wizard Find the latest Setup Wizard on our Mydlink site.
Make sure to select the correct model and version.
13.1.2016 Download
Version Description Date
DNR_2020_04P_Cam_Support_list DNR-2020-04P Camera Support List 22.9.2016 Download
DEU_Quick_Guide_on_mydlink_Cameras_Rev Quick Guide on mydlink Cameras 03.12.2014 Download
CE declaration CE declaration 16.10.2014 Download
