ShareCenter™ 2-Bay Network Storage Enclosure

DNS-320, DNS-320-1TB, DNS-320-2TB, DNS-320-4TB

  • Estado del producto (Revision B): End of Life

The ShareCenter™ 2-Bay Network Storage, when used with internal SATA drives*, enables homes and offices to share documents, music, photos, and videos across the network and on the Internet, so family members, friends, or employees can easily access them. This device also allows for the creation of a central network point for backing up files and the built-in RAID 1 mirroring technology protects these files from drive failure. This device can be used to stream music, photos, and videos to UPnP AV compatible network media players. The ShareCenter™ 2-Bay Network Storage is also available with preinstalled hard disk drives with 1TB, 2TB or 4TB storage*.

Safely Share Digital Files Locally And Over The Internet

The ShareCenter™ 2-Bay Network Storage Enclosure, when used with internal SATA drives*, enables users to share documents, files, and digital media such as music, photos, and videos with other users on a home or office network. Remotely accessing files through the Internet is also possible using the built-in secure FTP server and web file server. Keep data safe by giving rights to specific users or groups and assign them to folders with specific read/write permissions. This function is ideal for the home, where children’s access can be restricted to only age-appropriate materials.

Stream Digital Media Content With Built-in Media Server

Back up your digital media files to the ShareCenter™ for safekeeping, and enjoy the benefits of the built-in UPnP AV media server. Stream digital content to compatible media players such as the PlayStation 3, Microsoft Xbox 360, or D-link’s Boxee Box.

Access Your Personal Files From Anywhere

The ShareCenter™ includes a web file server which allows you to download your documents, photos, and other multimedia files from anywhere. Once configured, simply log into your ShareCenter™ using the friendly web user interface to view a listing of available files. A convenient USB port on the front of the ShareCenter™ can be used to attach external USB storage drives, USB printers, or an Uninterruptible Power Supply (UPS) for monitoring.

Enjoy Performance, Protection, And Flexibility

The availability of four different hard drive modes (Standard, JBOD, RAID 0, RAID 1) allows users to choose the configuration best suited to their needs. Standard mode creates two separately accessible hard drives. JBOD combines both drives to create a single, easy to use volume. RAID 0 combines both drives in a “striped” configuration, which provides the highest performance when using a Gigabit Ethernet connection. RAID 1 creates a copy of your data on both drives, providing maximum protection; if one drive fails while configured as RAID 1, the unaffected drive continues to function as a single drive until the failed drive is replaced. The new drive will then be re-mirrored, allowing the ShareCenter™ to return to its full level of protection.

Robust Software Included

The included CD contains D-Link’s Setup Wizard and Easy Search Utility, which allows users to locate the ShareCenter™ anywhere on the network. Once located, they can use the utility to map the hard drive(s) so they will appear in “My Computer” on their PC. Backup software is also included on the CD, allowing users to back up valuable files from a computer to the ShareCenter™ manually, according to a schedule, or in real-time. Real-time backups are a great way to safeguard against unforeseen data-loss.

Simple upgrade with Enhanced RAID Roaming

Enhanced RAID roaming allows the users to easily upgrade to the cloud NAS experience. Simply install existing hard drives from compatible D-Link NAS models into the Cloud Network Storage Enclosure and your data can be accessed from anywhere. There is no need to reformat, reconfigure or migrate your data (please refer to specifications for information on compatible upgrade models).

D-Link Green™

For consumers interested in reducing their energy costs and helping to save the environment, D-Link Green™ products provide eco-friendly alternatives without compromising performance. This device uses hard drive power management and Smart Fan speed control to reduce energy costs, minimize noise, and prolong the lifespan of your hard drives.

*SATA drives are not included with the DNS-320. DNS-320-1TB, DNS-320-2TB, DNS-320-4TB includes preinstalled 1TB, 2TB and 4TB storage respectively. Please refer hard disk compatibility list in the download section for more information.

Product Awards

Premios de diseño red dot 2012
Cuatro de los últimos productos de D-Link, el sistema de almacenamiento en red DNS 320L, la cámara DCS 6010L, el adaptador de corriente inalámbrico DHP W310AV y el minirrouter DWR 910 han sido galardonados con el premio de diseño de productos red dot 2012. Los premios de diseño red dot son el galardón internacional más importante y conocido en el sector del diseño industrial. Cada año, destacados diseñadores y expertos de todo el mundo evalúan productos basándose en criterios como el grado de innovación, la funcionalidad y la calidad general. Este año, más de 4.500 productos compiten para conseguir esta apreciada distinción.

Specs

Type
Network Attached Storage
Enclosure form factor
Desktop
CPU
Marvell 88F6281 800 MHz
FLASH
128 MB
SDRAM
128 MB
Number of drive bays
2
Drive interface
SATA I/II
Drive form factor
3.5 inch
Maximum storage capacity
8 TB
Network interface
1 x Gigabit Ethernet
Number of USB ports (for storage backup, printer sharing or UPS monitoring)
1
D-Link Green with power saving mode and smart fan
Supported
Multiple drive configuration
JBOD
RAID 0/1
standard
RAID migration non-RAID to RAID 1
Supported
Drive format
EXT3
Scan disk
Supported
SMART
Supported
Disk/RAID roaming
Supported
User account management
Supported
Maximum number of user accounts
256
Group account management
Supported
Maximum number of group accounts
32
User/group quota management
Supported
Network share management
Supported
Maximum number of managed shared forlders
128
Maximum concurrent connections via FTP
10
Maximum concurrent connections via Samba
64
Schedule backup from PC to NAS
Supported
Schedule local backups
Supported
Schedule remote backups
Supported
Apple Time Machine support
Supported
Cloud storage backup
Amazon S3
D-Link Vault
Dropbox
Google Drive
USB backup
Supported
FTP/HTTP/P2P downloads
Supported
File sharing protocol
CIFS/NFS/Web File Manager/AFP/WebDAV
Network streaming service
DLNA
iTunes Server
UPnP AV
Web interface through browser
Supported
E-mail/SMS notification
Supported
System/FTP log
Supported
This product was phased out on: 06/09/2015
Última fecha de asistencia 05/09/2017
