Cloud Gigabit Router N600 with SmartBeam Technology


  • Estado del producto: End of Life

D-Link’s Cloud Gigabit Router N600 with SmartBeam™ Technology extends the coverage of your wireless network, giving you a strong and stable Internet connection in every corner of your home. Integrated Dualband Technology allows you to receive two wireless networks in one; so you can check your email or surf the Internet on the 2.4GHz band, and stream on the less commonly used 5GHz band, providing you with an improved performance and seamless media. By downloading the free mydlink™ app you can also monitor your home network from wherever you are for total peace of mind courtesy of D-Link’s unique mydlink™ Cloud Services.

A fast and reliable home network
Concurrent dualband 802.11n brings you high-bandwidth wireless connectivity allowing you to stream HD video, make Internet calls, and surf the Internet from every corner of your home without interruption. Gigabit Ethernet ports provide high-speed wired connections for up to four PCs or other devices. It’s stylish, easy to use, and comes IPv6-ready for a reliable network today and tomorrow.

Revolutionary SmartBeam™ Technology
SmartBeam™ Technology uses 6 multi-directional antennas to find and track individual devices, then focus beams of bandwidth to those particular devices, ensuring a seamless connection anywhere in the home, even in corners where wireless access was previously not able to reach. Eliminate wireless dead spots and unleash comprehensive whole-home coverage on all your devices, all at once, providing you with uninterrupted connectivity anywhere in your home.

Stay informed and protected with mydlink™ Cloud Services
This router allows you to create a high-speed home network with security features that are great for families. With mydlink™ Cloud Services you can monitor your network from wherever you are via the mydlink™ web portal or free app for your iPhone®, iPad® or Android™ device. By setting up a mydlink™ Cloud Services account you can receive email alerts to keep you informed anywhere and anytime when new devices are connecting to your network or unwanted access is detected. You can also monitor in real-time which websites are being visited with the recent browser history displayed on the mydlink™ app - great for parents.

Share and stream files
The SharePort™ free mobile app for iOS and Android™ devices allows you to back up photos and files and videos stored on your device. You can share your music with everyone but keep your personal files private. This Cloud Router can also be used as a media server for your home to stream media stored on your USB storage drive to any DLNA compliant player like the Boxee Box by D-Link.

Easy to set up and use
Get this router up and running in no from your living room using the QRS (Quick Router Setup) Mobile app on your iOS or Android™ device. Simply plug in the router, open the app, and follow a few easy steps to get your home network connected without having to turn on your computer. You can also set up a secure network at the touch of a button using Wi-Fi Protected Setup. Simply press the WPS button to instantly establish a secure connection with your new device.

D-Link Green™
D-Link’s Cloud Gigabit Router N600 is part of D-Link Green™, D-Link’s programme for providing eco-friendly alternatives without compromising performance. The  DIR-845L supports Green Ethernet technology, which reduces power consumption by setting Ethernet ports in stand-by mode if no traffic is detected. The WLAN Scheduler function turns off your wireless network when it is not needed, for example at night or during weekends. Also power consumption is further reduced with its Energy Star™ power supply.


  • IEEE 802.11n/g/b
  • IEEE 802.3/u/ab
  • IEEE 802.3
  • IEEE 802.3u

Device Interfaces

  • 802.11n/g/b Wireless LAN
  • Four Gigabit LAN ports
  • Gigabit WAN port
  • USB 2.0 port

Minimum System Requirements

  • Windows 7/Vista/XP SP3 or Mac OS X 10.4 or higher
  • Microsoft Internet Explorer 6 or higher, Firefox 1.5 or higher, or other Java
  • enabled browser
  • CD-ROM
  • Network Interface Card
  • Cable or DSL Modem
  • Subscription with an Internet Service Provider


  • WPA & WPA2 (Wi-Fi Protected Access)
  • Wi-Fi Protected Setup (WPS) - PIN/PBC

Advanced Features

  • Guest Zone
  • Web File Access
  • Multi-language Web Setup Wizard
  • Green Ethernet
  • UPnP support
  • Dual Active Firewall:
  •  Network Address Translation (NAT)
  • Stateful Packet Inspection (SPI)
  • VPN passthrough/multi-session PPTP/L2TP/ IPSec

Mobile App Support

  • SharePort™ Mobile
  • QRS Mobile
  • mydlink™ Lite

Operating Temperature / Operating Humidity

  • 0 to 40 °C
  • 10% to 90% non-condensing

Dimensions (L x W x H)

  • 99 x 119 x 191 mm


  • 330 grams


  • FCC Class B
  • CE Class B
  • C-Tick
  • Wi-Fi
  • Wi-Fi Protected System (WPS)
  • Wi-Fi Multimedia (WMM)
  • IPv6 Ready
  • Compatible with Windows 7


  • What file types are supported by SharePort Mobile? Ver respuesta
This product was phased out on: 09/04/2016
Última fecha de asistencia 09/04/2018
How to connect to wireless in Windows 8
How to connect to wireless in Windows 7
How to Change/Recover your lost wireless password
How to add your router to your Mydlink account
How to use the Mydlink SharePort app on your iPhone/iPad
How to connect to wireless using an iPhone
How to configure SharePort Mobile
How to upgrade the firmware on your router
How to configure the Wireless Settings on your router
How to remove the Graphical Authentication login on your router
How to change router password
How to configure Parental Controls on your router
How to configure IP reservation on your router
How to reset a router
How to change your routers IP address
How to open a range of ports on your router
How to open a single port on your router
How to disable UPnP on your router
Versión Fecha Tipo Tamaño de archivo
Datasheet - PDF 1.09mb Descargar
Versión Descripción Fecha Tipo Tamaño de archivo
Product manual

Product manual

02/09/2014 PDF 10.91mb Descargar
Versión Descripción Fecha Tipo Tamaño de archivo
1.00 Quick Installation Guide - PDF 1.25mb Descargar
Este producto de D-Link utiliza programación de software realizada por terceros, incluyendo código software sujeto a la GNU General Public License ("GPL") o GNU Lesser General Public License ("LGPL"). Los términos de uso de GPL y LGPL, así como información de acceso al código GPL y LGPL usados en este producto, están disponibles en:
Los códigos GPL y LGPL usados en este producto se distribuyen SIN GARANTIA y están sujetos a los derechos de uno o más autores. Para más detalles, vea los códigos GPL y LGPL para este producto y los términos de uso de GPL y LGPL.
Versión Descripción Fecha Tipo
1.03B05 Beta - 05/11/2018 - Descargar
Firmware Release notes included 1.02b05 Firmware
  • Release notes included
16/05/2014 - Descargar
Versión Descripción Fecha
CE doc 1.20 Revision A1 CE document 19/09/2014 Descargar
How_to_enable_Java_on_Mac_OS_X_for_mydlink How to enable Java on Mac OS X for mydlink 12/08/2013 Descargar
DEU_CE_Doc_A1_RevA CE Declaration 10/09/2012 Descargar
DEU_mydlink_routers_cheat_sheet_RevA mydlink routers cheat sheet - Descargar
