Fast Ethernet Smart Managed Switches

DES-1210 Series

  • Estado del producto (Hardware version: Bx): End of Sale
Conoce las Soluciones Smart de D-Link


Taller para Segmentar y Securizar tu Red con Smart


The DES-1210 Series Fast Ethernet Smart Switches consists of:

  • DES-1210-28P: 24-Port Fast Ethernet PoE Smart Switch with 4 Gigabit Ethernet ports (including 2 Combo SFP) (24 x PoE ports, smart fans)

The DES-1210 Series is the latest generation of Smart Switches. Equipped with 8, 24 or 48 Fast Ethernet ports, 2 Gigabit ports and 2 combo Gigabit/SFP ports, this series offers all the features needed in a small and medium business, without the complexity or cost involved. The built-in web interface and PC based SmartConsole Utility make these switches easy to deploy, configure and troubleshoot. Its complete set of features allows for seamless integration in every environment.

The PoE option is available on the 8 and 24 port members of the family. Integrating technologies such as time-based PoE which allows the power to be shut off at a predetermined time, saving power on VoIP phones, Wireless Access Points or any other PoE equipment. The DES-1210-28P utilises Smart Fan feature, automatically turning on the system fans only when necessary. This not only saves energy and cost but it also extends the lifespan of the switch. The DES-1210-28P is also compliant with the new PoE+ standard, enabling it to feed up to 30 Watts to connected devices.

Extensive set of Features

Equipped with a complete line-up of features, these switches include Quality of Service, Port Trunking, Spanning Tree and IGMP snooping. Network monitoring and maintenance features include Port Mirroring, Loopback Detection and the innovative Cable Diagnostics. With Cable diagnostics, the switch will flag a faulty Ethernet cable connected to any of its ports, detailing the type of error detected.

Ready for network convergence

These switches are ideal for converged networks, where IP telephony/VoIP, IP surveillance systems and traditional data traffic are integrated in the data flow. The Auto Voice and Auto Surveillance VLAN features will automatically place these types of traffic on separate VLANs, thus guaranteeing the confidentiality, prioritisation and quality of these services on the network.

Secure your Network

The DES-1210 series support RADIUS authentication, to ensure that only authorised users are able to log into the network. In addition, the Access Control List (ACL) feature further enhances security by ensuring that network resources are accessible only by their legitimate users. In addition, the DES-1210 Series protects against the most widespread network attacks, such as ARP spoofing or rogue DHCP servers. Smart Binding manages unwanted access to your network. This is done by checking IP and MAC address on a particular port against a pre-configured database before allowing or denying access.

Avoid Network Disruption

D-Link’s innovative Safeguard Engine protects against traffic flooding caused by broadcast storms or virus attacks, blocking traffic that reaches the definable threshold and avoiding network lock-ups before they occur. Spanning Tree (STP) and Rapid Spanning Tree (RSTP) allow for redundant paths in a network to ensure servers and other resources are always available.

Versatile Management

The new generation of Smart switches is provided with an intuitive PC-based SmartConsole utility and a friendly web interface that enables administrators to configure and control their network down to the port level. The SmartConsole automatically discovers multiple D-Link Web Smart Switches within the same network segment, so administrators can access all of them even before they have been configured. This allows for very quick deployments and initial setups, including firmware upgrades. For more advanced administrators, the DES-1210 series supports a Command Line Interface (CLI) accessible with Telnet.

Otros usuarios también vieron

D-View 7 Network Management System
DV-700
Más información
Módulo Mini-GBIC 1 Puerto LC 1000BaseLX Monomodo (3,3V, hasta 10 km)
DEM-310GT
Más información
Módulo Mini-GBIC 1 Puerto LC 1000BaseSX Multimodo (3.3V, hasta 550m)
DEM-311GT
Más información
Transceptor de fibra óptica multimodo Mini GBIC a 100BaseFX
DEM-211
Más información
Number of ports
16 to 30 ports
48 to 54 ports
5 to 14 ports
Layer
Layer 2
Main type of ports
100BASE-TX Fast Ethernet
Type of uplink ports
Combo 1000BASE-T/SFP
SFP
Switching capacity
1.6 Gbps
12.8 Gbps
17.6 Gbps
PoE options
802.3af
802.3at
Number of PoE ports
24
8
PoE power budget
See datasheet
See datasheet
Fanless
Supported
D-Link Green
Supported
Form Factor
Desktop
Rackmountable
MAC address
16K
8K
Spanning Tree Protocol
802.1D STP
802.1w RSTP
Link aggregation
802.3ad
VLAN group (max static)
256
Advanced VLAN
Asymmetric VLAN
Auto Surveillance VLAN
Auto Voice VLAN
IPv6 Ready
Supported
Number of QoS queues per port
4
CoS based on contents
Supported
Bandwidth control
64 Kbps minimum granularity
ACL type
Ingress
ACL based on packet contents
Supported
Encryption protocol supported
SSL (v1/v2/v3)
IP-MAC-port binding (IMPB) / Smart Binding
Supported
ARP spoofing
Supported
802.1X access control
Supported
SNMP (v1/v2c/v3)
Supported
RMON v1/v2
Supported
LLDP-MED
Supported
ICMPv6
Supported
This product was phased out on: 13/01/2024
