Wireless N 5GHz PoE Outdoor Access Point with PoE Pass-Through

DAP-3410

  • Estado del producto: End of Life

The DAP-3410 Wireless N 5GHz PoE Outdoor Access Point with PoE Pass-Through is the ideal solution for expanding the coverage and signal strength of any wireless network. Built to withstand harsh environments, the DAP-3410 also excels in connecting separate networks that cannot be joined physically using Ethernet cable or fibre5.



Dynamic

Multiple operating modes, network management tools and security features give network administrators a wide range of choices for deploying the device, allowing for the addition of increased connectivity to wireless network-enabled devices.





Product Highlights



Durable

Built to withstand harsh outdoor environments with waterproof IPX6 standard2

Flexible

PoE powered with PoE pass-through to allow for flexible installation as well as supply additional power to another PoE powered devices such as a network camera4



dd-wrt compatible

Supports dd-wrt for advanced configuration

Multi Task

Multiple operational modes including access points, WDS, WDS with AP, wireless client, wireless repeater, WISP client router or WISP repeater



Distance

Long distance wireless networking with WDS and WISP



Secure

Secure wireless connectivity with WAP/WPA2



Increased Network Connectivity And Throughput

Expand current wireless network capacity with the less congested 5GHz frequency wireless band. In addition, two 10/100 Ethernet ports (one supporting PoE) allow for further network expansion through wired Ethernet connectivity. The built-in 15 dBi sector antenna has high power output1, ensuring that wireless coverage will cover even hard to reach locations. Whether trying to connect additional wireless devices such as smartphones or laptops, or bringing connectivity to networks separated by short distances, the DAP-3410 has it covered.

Flexible Deployment Options

The DAP-3410 features seven multiple operation modes, allowing it to adapt to any situation. As a standard wireless access point (AP) the DAP-3410 can connect to a wide range of devices. In wireless distribution system (WDS) mode it can expand current wireless coverage without the need for a wired backbone link5. As a wireless client it can connect to an existing AP, and expand the network physically with the two built-in 10/100 Ethernet ports. Repeater mode will extend current wireless coverage eliminating dead spots and weak signals. WISP mode functionality includes the ability to function as a client or repeater.

Fine-Tuned Control Over Network Resources

The DAP-3410 supports up to 8 SSIDs, allowing the administrators to logically divide the access point into several virtual access points all within a single hardware platform. Rather than having separate networks with several access points, administrators can deploy one single AP to support more than one application, such as public Internet access and internal network control to increase flexibility and keep costs down. The DAP-3410 supports 802.1Q VLAN Tagging, operating with multiple SSIDs to segment traffic to enhance performance and security.

Robust Security And Management Tools

The DAP-3410 supports 64/128-bit WEP data encryption and WPA/WPA2 security functions. In addition, it provides MAC Address Filtering to control user access, and the Disable SSID Broadcast function to limit outsiders’ access to the internal network. Network administrators have multiple options for managing the DAP-3410, including HTTP and HTTPS. For advanced network management, administrators can use SNMPv1, v2c, v3 to configure and manage access points.

Dynamic & Secure

The DAP-3410 provides WLAN partitioning, a useful function for deployments such as hot spots. With station-to-station partitioning enabled, security is enhanced, since wireless users cannot peek at each other, and the possibility for data theft is reduced.

Power over Ethernet (PoE)

The DAP-3410 is powered by PoE5 which allows for convenient installation, especially in places where a power supply is not reliable or power cables are not available or easily set up. Also, the DAP-3410 can supply power to a connected surveillance camera through PoE, including the DCS-3716, DCS-6113, and DCS-7110 cameras.

1 Maximum power setting will vary according to individual country regulations.
2 IPX6 standard means the device is protected from low pressure jets of water from all directions - limited ingress permitted. It is recommended to place this device under a roof, shelter or in weather-proof box when deployed in severe weather environments.
3 Maximum wireless signal rate derived from IEEE Standard 802.11g, and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors may adversely affect wireless signal range.
4 Provides a secondary Ethernet port with POE output for supported D-Link IP cameras. The supported cameras include D-Link DCS-3716, DCS-6113, and DCS-7110.
5 WDS mode only works with other DAP-3410 access points
6 Although compatible with  DD-WRT, please be advised that if DD-WRT is used this will void your warranty and D-Link will not accept responsibility or support any products that may  adversely be affected as a result of using  DD-WRT.

Type
Software Managed AP
Wireless standard
Wireless N
Wireless speed
300 Mbps 5 GHz
Antenna type
Embedded sector antenna
Antenna gain
15 dBi for 5 GHz
Power-over-Ethernet
Yes
Wired interface
2 x Fast Ethernet LAN
Indoor/outdoor
Outdoor
Type of housing
Plastic
IP rating
IPX6
Wireless modes
Access Point (AP)
WDS bridge
WDS with AP
Wireless client
Advanced features
MIMO
Maximum number of SSIDs
8
Auto channel selection
Supported
WMM-PS/802.11e (U-APSD)
Supported
Wi-Fi scheduler
Supported
WEP 64/128 bit
Supported
WPA/WPA2-Personal/Enterprise
Supported
TKIP/AES encryption
Supported
WPA_WPA2_PSK over WDS
Supported
SSID broadcast disable
Supported
Station isolation
Supported
MAC address filtering
Supported
802.1X authentication
Supported
WEB
Supported
SNMP (v1, v2c, v3)
Supported
Telnet
Supported
SSH
Supported
This product was phased out on: 19/11/2016
Última fecha de asistencia 19/11/2018
