Wireless N PoE Outdoor Access Point with PoE Pass-Through

DAP-3310

  • Product Status: End of Life

The DAP-3310 is a Wireless N Outdoor Access Point with PoE Pass-Through ideal for expanding wireless coverage or increasing signal strength of any wireless network. Built to withstand harsh environments, the DAP-3310 excels in connecting separate networks that are not joined by a physical cable.

Simplified outdoor connectivity

Low cost Outdoor Access Point, with high power radio design the DAP-3310 is ideal for providing wireless connectivity between two locations.

Broadcast on 8 SSIDs Simultaneously

Supports up to 8 SSIDs per Band that can logically divide the access point into several virtual access points all within a single hardware platform.


Attractive Design

Featuring a clean unobtrusive design, the DAP-3310 can be mounted easily onto any wall or pole. Designed with a PoE pass-through port, the DAP-3310 can also be used to provide power to other devices such as an external camera for added security.

Wireless N mbps Range Single band outdoor


Product Highlights

Durable
Built to withstand harsh outdoor environments and be waterproof to the IPX6 standard

Flexible
PoE powered with PoE pass-through to allow for flexible installation, as well as supply additional power and network connectivity to another PoE powered device, such as a network camera

Adaptable
With 7 operational modes including access points, WDS, WDS with AP, wireless client, wireless repeater, WISP client router or WISP repeater, the DAP-3310 meets the needs of any situation.

Secure
Secure wireless connectivity using WPA/WPA2 data encryption and MAC address filtering wireless access can be controlled

2.4Ghz Single-Band Wireless

With a high power radio design and built-in high gain sector antenna,
the DAP-3310 supports up to 300Mbps throughput for the 2.4Ghz band

Type
Software Managed AP
Wireless standard
Wireless N
Frequency band mode
Single-band
Antenna type
Embedded sector antenna
Antenna gain
10 dBi for 2.4 GHz
Power-over-Ethernet
Yes
Wired interface
2 x Fast Ethernet LAN
Indoor/outdoor
Outdoor
Type of housing
Plastic
IP rating
IPX6
Wireless modes
Access Point (AP)
WDS bridge
WDS with AP
Wireless client
Geavanceerde Eigenschappen
MIMO
Maximum number of SSIDs
8
Auto channel selection
Supported
WMM-PS/802.11e (U-APSD)
Supported
Wi-Fi scheduler
Supported
WEP 64/128 bit
Supported
WPA/WPA2-Personal/Enterprise
Supported
TKIP/AES encryption
Supported
WPA_WPA2_PSK over WDS
Supported
SSID broadcast disable
Supported
Station isolation
Supported
MAC address filtering
Supported
802.1X authentication
Supported
WEB
Supported
SNMP (v1, v2c, v3)
Supported
Telnet
Supported
SSH
Supported
This product was phased out on: 24/04/2016
De laatste dag dat ondersteuning beschikbaar is voor dit product is op: 24/04/2018
Versie Datum Type Bestandsgrootte
- PDF 0.67mb Download
Versie Beschrijving Datum Type Bestandsgrootte
- - PDF 3.60mb Download
Dit D-Link product bevat software code welke ontwikkeld is door derden, waaronder software code die valt onder de GNU General Public License ("GPL") of GNU Lesser General Public License ("LGPL"). Indien van toepassing: de voorwaarden van de GPL en LGPL en informatie over het verkrijgen van toegang tot de GPL-code en LGPL-code die in dit product zijn gebruikt, zijn hier voor u beschikbaar:

http://tsd.dlink.com.tw/GPL.asp

De GPL-code en LGPL-code die gebruikt is in dit product wordt gedistribueerd ZONDER ENIGE GARANTIE en is onderworpen aan de auteursrechten van een of meer auteurs. Voor meer informatie, zie de GPL-code en de LGPL-code voor dit product en de voorwaarden van de GPL en LGPL.
Versie Beschrijving Datum Type
Firmware Release notes included 1.10rc19 Firmware
Release notes included
15-5-2015 - Download
Versie Beschrijving Datum
CE doc 2.00 RevA1

CE Documentation

23-7-2019 Download
CE Declaration CE Declaration - Download
