8-Port 10/100 Switch

DES-1008A

  • Product Status (Revision E1_v100): Live
  • Eight Fast Ethernet LAN ports for high-speed wired connections
  • Compliant with IEEE 802.3az Energy-Efficient Ethernet (EEE)
  • D-Link Green Technology features power-saving by link status and by cable length
  • Auto-sensing ports automatically detect network connections and adjust accordingly

Download the datasheet.

Where to buy

Wired Network Setup Made Faster

The DES-1008A 8-Port 10/100 Switch is an 8-port 10/100 Mbps Fast Ethernet switch that allows you to quickly set up a wired network. Use the DES-1008A to connect multiple computers together to share files and folders, or connect it to a router to share an Internet connection.

Auto-sensing 10/100 Ports

The D-Link DES-1008A 8-Port 10/100 Switch uses auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to Ethernet and Fast Ethernet devices to create an integrated network. These ports detect the network speed and auto-negotiate between 10BASE-T and 100BASE-TX, as well as between full and half-duplex, allowing you to get the maximum speed possible for each device connected to your network.



Flow Control for Secure Transmission

802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full. This gives you a more reliable connection for all of your connected devices, ensuring a smooth and uninterrupted network connection.



Auto-MDI/MDIX Crossover

All ports support auto-MDI/MDIX crossover, eliminating the need for crossover cables or uplink ports. Each port can be directly connected to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables.

Acoustic
0 dB
Auto MDI/MDIX
Yes
Comply with RoHS 6
Yes
Control
802.3x Flow
Dimensions
141.5×78.5×23.8mm
FAN
Fanless
Interfaces
8 x 100Base-TX
MAC Address Table Size
1,024
Max. Packet Forwarding Rate
1.19 Mpps
Maximum Heat Dissipation
7.47228 BTU/hr
Maximum Power Consumption
2.19 W
MTBF
2,137,319 hours
Operating Humidity
10% ~ 90% RH
Operating Temperature
0 ~ 40 °C
Packet Buffer Size
0.06 MB
Power Input
AC:100 ~ 240 V
Storage Humidity
5% ~ 90% RH
Storage Temperature
- 10 ~ 70 °C
Store & Forwarding Forwading
Yes
Switching Capacity
1.6 Gbps
Weight
128 g
